Diesel Genset Iran Supplier - Iran

HOPI Group Supply the generator from 25kva to 3075 kva that it can make the frame type or canopy type.

we will supply the brand that engine is Cummins , MTU and Caterpillar and alternator is Standford

MTU is one of the world’s leading manufacturers of large diesel engines and complete propulsion systems.

MTU brand engine is produced by the top one heavy duty diesel manufacturer in the world, which has awarded the highest honor.

From one hundred years ago until now MTU always is the outstanding delegate of the highest quality in industry, it is widely applied in marine, heavy duty auto, railway vehicles, mines, electric station and so on.

As the supplier of marine, railway motor system and land diesel generators’ engine, MTU is world famous with advanced technology, high reliability and top-ranking service.

In the military market, MTU always occupy 80% of this market.

MTU series DG set is assembled with MTU 2000 series and 4000 series diesel engine, and customer-chose alternator.

This product completely meets ISO 3046, ISO 4001, ISO 8525, IEC 34-1, GB1105, GB/T2820, CSH 22-2, VDE 0530 and YD/T 502-2000 standards etc.

Futures:

More than three hundreds engine states & fault codes.

Electronic management system(2000 series MDES, 4000 series ADEC)—MDEC’s performance is superexcellent, it can furthest perfect engine’s performance.

Fuel consumption rate is lowest in all of the world.

The longest working life, the first overhauling is more than 24000 hours.

Perfect alarm system, fault auto- diagnosis and auto-display, intellectualized operation.

Key technologies:

Turbocharging: key technology for high-performance engines.

Common Rail Fuel Injection: Key technology for clean and economical combustion.

Electronic Engine Management: Key technology for the intelligent control of the drive system

Exhaust Gas Recirculation: Internal engine technology for reducing nitrogen oxide emissions

Diesel Particulate Filter: Exhaust aftertreatment for the reduction of soot emissions.

Selective Catalytic Reduction: Exhaust aftertreatment for reducing nitrogen oxide emissions.

Genset Type Power Engine Model Fuel Consump-tion(l/h) Engine Weight (kg) Dimension L*W*H (mm)

Prime Kw/Kva Standby Kw/Kva Cylinder Bore (mm) Stroke (mm) Displace-ment (L)

HPMT240 218/272 240/300 6R1600G10F 63 6 122 150 10.5 3078 3658 x 1445 x 1855

HPMT264 240/300 264/330 6R1600G20F 69 6 122 150 10.5 3078 3658 x 1445 x 1855

HPMT320 292/365 320/400 8V1600G10F 82 8 122 150 14 3992 3255 x 1871 x 1975

HPMT350 320/400 352/440 8V1600G20F 91 8 122 150 14 3992 3255 x 1871 x 1975

HPMT400 360/450 400/500 10V1600G10F 100.3 10 122 150 17.5 4047 3385 x 1875 x 1946

HPMT440 400/500 440/550 10V1600G20F 111.7 10 122 150 17.5 4047 3385 x 1875 x 1946

HPMT520 472/590 520/650 12V1600G10F 127.9 12 122 150 21 4545 3715 x 1900 x 2047

HPMT570 520/650 572/715 12V1600G20F 140.8 12 122 150 21 4545 3715 x 1900 x 2047

HPMT720 640/800 720/900 12V2000G65 186 12 130 150 23.88 5477 4242 x 1750 x 2072

HPMT800 720/900 800/1000 16V2000G25 214 16 130 150 31.84 6210 4150×1450×2290

HPMT880 800/1000 880/1100 16V2000G65 239 16 130 150 31.84 6580 4450×1450×2290

HPMT1000 896/1120 1000/1250 18V2000G65 270 18 130 150 35.82 7680 4600×1910×2465

HPMT1150 1040/1300 1144/1430 12V4000G21R 288 12 165 190 48.72 10000 5050×2240×2920

HPMT1320 1200/1500 1320/1650 12V4000G23 310 12 170 210 57.2 12180 5550×2240×2920

HPMT1470 1336/1670 1470/1837 12V4000G23 323 12 170 210 57.2 12560 5750×2240×2920

HPMT1670 1520/1900 1672/2090 12V4000G63 366 12 170 210 57.2 12560 5750×2240×2920

HPMT1880 1720/2150 1880/2350 16V4000G23 416 16 170 210 76.32 14750 6310×2610×2920

HPMT2000 1828/2285 2008/2510 16V4000G63 452 16 170 210 76.32 16460 6310×2610×2920

HPMT2300 2088/2610 2296/2870 20V4000G23 517 20 170 210 95.4 19050 6640×2910×3230

HPMT2530 2296/2870 2528/3160 20V4000G63 563 20 170 210 95.4 19150 6710×2910×3230

HPMT2700 2460/3075 2704/3380 20V4000G63L 599 20 170 210 95.4 20150 6800×2910×3230

Notes:

(1) 50Hz/60Hz.

Also avaliable in the following voltage：LV (400)380-690V, MV 3.3KV-13.8KV.

(2) The weights are approximate.
