Anaerobic Sludge Bioreactor 7 8 - China

The institute is a high-tech enterprise in researching developing and

producting auto-control bioreactor (fermenter), auto-control reaction

kettle and microalgae production equipment，which is also the

earliest professional institute in China and awarded the title of high-

tech enterprise of Shandong Province.

The institute owns solid technical

force and equipment manufacturing base.

The development of the

microalgae and the large algae depends on School of Life Sciences of

Ocean University of China and Yantai University.

Contact: Cao director（Engineeri ng）

TEl: 86-0535-6714995 15318650506

FAX: 86-0535-3452749


Email: yt.

haiyang@163 - c om

Website: www.

ythysw.

cn

www.

ythysw.

com

Anaerobic sludge bioreactor

GBR series auto-control bioreactor has been already appraised by the experts of Shandong Science and Technology Commission.

After that，it uses the new technology increasingly and strives for the development.

Now it has already formed the GRB series entire automatic control，half automatic control bioreactor and the light bioreactor volume production.

The product has sold to the nation and exported to Asian and the Mideast.

Control system

Siemens PLCcontroller true color touch screen with complete functions and stable running.

Bioreactor features

Without driving leakage risk;

Wide visual angle vertical sight glass with clear observation;

Sealed feed system;

Floor type tank with beautiful appearance;

Easy operation, assembly and disassembly;

Bioreactor pressure control

The top exhaust port is equipped with the pointer pressure gauge to display the tank pressure.

The stainless steel valve adopts manual control.

The optional pressure transmitter and automatic control valve realize automatic control of tank pressure.

Temperature control

Online inspection, PLC setting, free switching between automatic and manual control;

The optional imported pressure transmitter and automatic control valve realize automatic control of tank pressure.

pH control(optional)

Online inspection, 2-way peristaltic pump automatic incremental feeding of acid or alkali solution for adjustment;\

Switzerland pH electrode realizes high temperature steam disinfection.

Feeding control

Standard configuration 1-way large-flow peristaltic pump time quantitative incremental feeding, with the volume of incremental or accumulation feeding being displayed and recorded.

Equipped with Mettler Electronics said and transmitter to make sure the accuracy and repeatability of feeding

Nominal volume

20L-1000L

Bioreactor configuration

Stainless steel SUS316L/SUS304;

Jacket temperature control;

Interior/ external surface polishing, Ra≤0.6μm;exter ior surface polishing or matte treatment;

Wide visual angle long-bar sight glass, automatic quantitative feeding, temperature electrode with complete connections;pH electrode(optional);

The tank cover is equipped with the flame inoculation port and standby feeding port.

Stirring system

Tip mechanical stirring system, aseptic mechanical seal system, DC stirring motor or AC motor.

Oblique vane, benging vane and axial flow vane are optional;

Speed control available, PLC settingof rotation speed control.

Exhaust gas collection system

Sealed feeding tube;

Wet flowmeter, low pressure operation, cumulative flow and instantaneous flow;

Optional

1, Multi-way feeding

2, Weighing of fed materials

3, Tank body weighong

4, Rich oxygen bypass

5, ORP online inspection

6, pH online inspection

7, Air flow automatic inspection and control

8, Tail gas O2, CO2 content online inspection

9, Methanol(alcohol)content online inspection
