Fuel Injection Hose Serves Longer Saves More Fuels - China

price: contact company for price

Fuel injection hose features ultra-low permeation and high

working pressure. It is not only used in fuel injection

systems, but also universally used in all fuel systems, such

as power steering systems.

For different purposes, fuel injection hoses are separated

into two types – fuel injection return hose and fuel

injection pressure hose. The former is especially used on

the non-pressure side (up to 50 psi), while the latter is

usually found in the pressure side up to 225 psi. Both hoses

are friendly to environment for their super low permeation

and apparently save fuel in contrast to conventional rubber

hoses. They are extensively used in cars, light trucks and

other small engines.


Super low permeation

Working temperature: -40°F to 257°F (-40° C to 125°C)

Length: 25’, 50’ or 250’


Fuel injection hose consists of five plies (from inner to

outer): tube, barrier, adhesion layer reinforcement and


Fluoroelastomer rubber tube is famous for its ultra-low

permeation and chemically inertness. It is quite compatible

with gasoline (leaded and unleaded), diesel, biodiesel up to

E85, methanol, ethanol and other fuel blends.

Thermoplastic barrier layer is designed for reducing fuels

permeation. It is an effective to prevent emitting hydro-

carbon vapors into the environment.

Adhesion layer is designed as the second defence when the

tube fails. It bounds together with the thermoplastic

barrier, reinforcement and cover.

Reinforcement is made of textile spiral layers. It is not

suitable for pressure side for its maximum working pressure

is 50 psi.

CSM cover has excellent performances in resisting ozone

deterioration, abrasion, heat, oils, acids and weather.

Company Contact:

  • Phone: 8631858943265

  • Address: NO.16 Development zones, Jingxian, Hengshui, Hebei, Hengshui, China

  • Email: Email

Published date: January 28, 2013 -

  • Business Description: Conflex oil hose Co., Ltd. as a leader of China oil hose industry is

    getting recognized by increasing customers at home and abroad. As we all

    know, oil hose industry is getting increasingly intensive. A number of

    small companies make use of extraordinary price to attract buyers'

    attention. However, this action not only runs counter to the principle

    of fair competition, but also deceives customers' trust for their hoses

    are often inferior to qualified ones.

    Conflex oil hose Co., Ltd. is always believed that we help our customers to buy what they really need. Our company says no to inferior products and says yes to high quality ones.

    Our people

    Our employees including administrative staff and workers at the spot belief one thing quality speak louder than anything. This can be apparently reflected to our products which have been sent to a lot of regions and orders are rising continuously. Regular training courses are held to improve our staff professional knowledge and broaden their visions of advanced manufacturing process.

    Our products

    Conflex oil hose Co., Ltd. is committed to manufacturing, designing and dispensing oil hoses. Our fuel hoses mainly focus on petroleum, agriculture and automobile industries containing oil cooler hose, petroleum dispensing hose, fuel injection hose and so on. Premium materials are employed to give you peace of mind.
