We Not Only Offer High Pressure Hydraulic Hose And Also Supply Hoses That Used For Air Are Widely In - China

price: contact company for price

We not only offer high pressure hydraulic hose and also supply high

pressure hoses that used for air. High pressure air hoses are widely

used in underwater diving, for example scuba diving. It is an

important and part of diving dress and other types of surface supplied

diving equipment. In the other hand air hoses can be used for air

brakes between tractors and semi-trailers. The air high pressure hoses

can work in the operating pressure in excess of 300 bars that are

30Mpa and 4400 psi.

In the following we will introduce two types of air high pressure hoses: high pressure steel reinforced air hose and PVC air hose.

High Pressure Steel Reinforced Air Hose

Application:

Durable hose for compressed air which contains particles of lubricant.

It’s suitable for use in quarries, mines, tunnels, and construction of roads.

Indicators:

Braided steel wire can be used in extreme high pressure conditions

Sleeve, well distinguished color painting of the outer layer of rubber

Operating temperature:-35 ° C to +80 ° C

Safety factor: 5: 1

Inner layer: SBR, black, smooth. It’s suitable for air containing oil

Reinforcement: steel wire braid

Outer layer: SBR, yellow. It’s abrasion-resistant, weatherproof, and cloth impression.

Specifications

Inner diameter

(mm) Inner diameter

(inch) Wall thickness

(mm) Outer diameter

(mm) Operating pressure

(bar) Number of inserts Bending radius

(mm)

13.0 1/2 5.6 24.2 40 1 65

25.4 1 6.4 38.2 40 1 125

38.0 1-1/2 7.5 53.0 40 2 190

50.8 2 8.0 66.8 40 2 260

PVC Air Hose

PVC air hose is also called high pressure air hose tubing.

Construction and features:

The middle layer is made of high strength synthetic fiber.

Inner and outer layers are made of PVC compound material. They have high pressure resistance, good flexible and excellent durability, weather resistant, and chemical anticorrosion.

Application: general used on high-pressure industrial applications, compressed air in garages and service stations, factory air lines, pesticide spraying, automation machinery and pneumatic lines, etc.

Working temperature ranges from -10°C to +65°C.

Size (inch) ID OD Weight W.P. Length

Lb./ft. Kg/m psi MPA m/roll

1/4 0.26 6.5 0.47 12 0.073 0.109 300 2.0 100

9/32 0.30 7.5 0.51 13 0.081 0.121 300 2.0 100

5/16 0.33 8.5 0.55 14 0.089 0.133 300 2.0 100

3/8 0.39 10 0.63 16 0.113 0.168 300 2.0 100

1/2 0.51 13 0.79 20 0.166 0.248 300 2.0 100

5/8 0.63 16 0.98 25 0.266 0.397 300 2.0 100

3/4 0.75 19 1.12 28.5 0.325 0.485 300 2.0 100

1 0.98 25 1.36 34.5 0.408 0.6.8 220 1.5 50

1-1/4 1.26 32 1.73 44 0.658 0.981 220 1.5 50

1-1/2 1.50 38 1.97 50 0.762 1.136 220 1.5 50

2 1.97 50 2.52 64 1.151 1.716 150 1.0 50
