Sand Gravel Pump - China
price: 1150.00 Dollar US$
Introduction:
Slurry pump can be widely used in mines, electric power, metallurgy, coal, environmental protection and other industries transport slurry containing abrasive solid particles.
Such as metallurgical mill pulp conveying, hydraulic ash thermal power plants, coal washery coal slurry and heavy media delivery, dredging river, river dredging, etc.
In the chemical industry, also can carry some corrosive slurry containing crystallization.
Structure:
Single stage, single suction, overhang shaft, centrifugal, double-casing horizontal pump, Wet ends are made of abrasive resistant hard metal or rubber.
Base- High strengthened base is connected with Frame Plate by bolts; The Adjusting Bolt under the Bearing Assembly realize easy adjustment to impeller clearance.
Bearing Assembly:
-High rigidity shaft to handle heavy duty work condition;
-Cartridge bearing assembly jointed with base by bolts;
-Grease Lube bearings fitted in sealed bearing housing, the two labyrinth on both ends prevent the grease from contamination.
Shaft Sleeve - Clearance fit between solid solution treated stainless steel shaft sleeve and shaft as well as the O-rings on both ends prevent the shaft from abrasion and erosion.
Casing - Made of Gray Iron or Ductile Iron, Ribs help casing to stand high pressure.
Impeller - Pump out vanes on both shrouds reduces recirculation and seal pressure.
Wet Ends - Impellers, liners, volutes made of High-Chrome alloy or rubber, both materials are interchangeable.
Specification
DC Type: The output shaft of a motor is directly connected to the input shaft of a pump via a pump coupler.
This type of connection is suitable for applications where the speed of the slurry pump is the same as that of the motor.
CV Type: The pump is driven by a belt connected to the crankshaft of the engine.
This way of connection allows for saving space, easy installation, and fast adjustment of pumping speed.
The motor is fixed to the motor support frame which is located on the bearing support above the slurry pump.
ZVZ Type: Another type of belt drive that allows easy adjustment of pumping speed.
The motor is directly fixed to the bearing support.
This way of installation is suitable for motors with larger horsepower than is possible with
CV type of installation.
Due to the installation of motor onto the bearing support, this method helps save installation space.
Slurry Pump Spares
Pumps spare and parts material :
High chrome alloy: A33, A05, A07, A49, etc.
Natural rubber: R08, R26, R33, R55, etc.
Other material as per requests, like stainless steel, duplex stainless steel, Nickle alloy, Alloy 20, and so on.
Applications
Mining
Coal washery
Power plant
Metallurgy
Petrochemical
Building material
Dredging
Other industrial departments, etc.
This series of pumps are preferred by many customers with special installation requirements and
widely applied in pool.
Its wear-resistant metal liner could handle abrasive slurries with rough particles and high concentration.
Company Information
1 - Company Informations:
Established in 2003, Shijiazhuang Ruite Pump Co., Ltd. is a professional factory being engaged in the design and production of slurry pump, which has passed the ISO9001 certification.
Our products are widely used in mining, metallurgy, coal washing, power plant, sewage water treatment, dredging, and chemical and petroleum industries.
Thanks to the trust and recognition of our clients from many countries, we are becoming one of the most important slurry pump suppliers
After-Sales Service
Installation and Debugging
Manual, pilot testing data and related soft copies etc.
are provided.
Professional Technical Support
Our company’s technical specialists will help to check and solve our client’s questions and problems via Email and telephone.
Oversea Service Time
Our customers also can directly contact us for consult if necessary.
Our service is 24hors per day
FAQ
1 - Are you a trading company or manufacture?
We are Professional Slurry Pump Manufacturers.
And welcome to our factory to see our product line and our pump quality.
2 - we don't know which model we need, can you help us ?
yes, please let us know the pump capacity, head, then we can help you to calculate .
3 - Is your price the best ?
You get what you pay off.
We supply high effiency good performance slurry pump.
4 - What is the best delivery time?
Within 10-20 days.
5 - Warranty Period?
One year, except spare parts
6 - Why choose us?
13 years experiences professional manufacturer
Good quality with competitive pirce
Professional after-sales service
Contact
Shijiazhuang Ruite Pump Co., Ltd
Add: Majuan Village, Nandong Town, Shijiazhuang, Hebei, China (Mainland)
Tel: dsales3(at)ruitepu mp.
com
Fax: 86-0311-89916995
Contact: Hillary
Mob: 18332439492
Company Contact:
- Posted By: Shijiazhuang Ruite Pump Co.,Ltd.
- Phone: +8631187549492
- Address: Majuan Village, Nandong Town, Shijiazhuang, Hebei,, Shijiazhuang , Hebei , China
- Email:
- Website: https://www.ruitepump.com
Published date: December 5, 2016
- Business Description: Ruite Pump is one of the most well recognized slurry pumps manufacturers in China.
We offer slurry pumps, slurry pump parts and other OEM casting parts products and service.
If you want to find quality slurry pumps and spare parts manufacture, supplier and distributor, Ruite is your best Choice.
Just contact us and enjoy our amazing service.
AS an ISO 9001: 2000 certified company with more than 300 employees, we are offering a full range of pumps service, from making mould, casting, heat treatment, machining, slurry pump assembly to onsite service.
