Professional Manufacture Cheap Wall Mounted Shower Pannel - China

Body Frame 0.9mm (±0.02mm) thick SUS304 stainless steel with Ni(8.5% ~ 10.2%)

Surface Finish NO.

600 skill exquisitely brushed by manual work

Hot & Cold Water Mixer H59 (CuZn40 / C28000) Standard Brass Mixer precision casting technology

Mixer Cartridge Sedal Brand Ceramic Cartridge, Model No: 08SN35L0003 standard Ø35mm

Water Diverter H59 (CuZn40) Standard Brass Diverter, 4 functions, precision casting

Diverter Cartridge Sedal Brand Ceramic Cartridge Model No: 08GD35S0004 standard Ø35mm

Mixer and Diverter Handles Zinc Alloy with 3 layers of Ni & Cr electroplated, ≥15µm thick

Top head shower 1 set with 60 (10 x 6) self-clean silicon nozzles

Top waterfall Chromed ABS material

Back massage shower 4 sets of double-function plastic back massage jets

Hand shower Chromed ABS hand shower with strong acupuncture & fog-spraying functions

Hand shower hose 1.5m long stainless steel flexible shower hose with 304 stainless steel nut

Hand shower holder Chromed ABS material, adjustable

Water Spout/Tap/Faucet 90mm long round shape bottom water spout, chromed

Water Spout/Tap/Faucet switch Chromed ABS material, adjust the water between water spout and hand shower

Water-inlet pipe 2 pcs for hot & cold each, 40cm long, 304 stainless steel material

Back water circulation pipe Silver-grey PVC pipe with patent, 6 layers constructure, 3.2mm wall thickness

Back pipeline bolt White silicon bolt

Installation hook and screws 304 stainless steel material

Hose clamp 304 stainless steel material

Technology Testing

Salt spray testing Pass 48 hours standard

Water Pressure Testing 0.8Mpa/8Bar/8kg

Air Pressure Testing 0.8Mpa/8Bar/8kg

Min Operation Pressure 0.1Mpa/1Bar/1kg

Max Operation Pressure 1Mpa/10Bar/10kg

Cartridge Life Time Over 1, 000, 000 times to open and close

Quality control 100% test

Water flow Bath/Shower/Mixer >=181/min, other Mixer >=121/min

Intallaltion Wall Mounted, 2 pcs of 304 stainless steel hook fixed on the wall

Warranty 10 years for the main panel, 3 years for the spare parts

Price include Shower panel + All accessories for installation + Installation manual
