358 High Security Welded Mesh Fencing 2d And 3d Fence - China

price: contact company for price

358 mesh fencing - the highest level of security welded panel barrier

358 security mesh fence made from a type of strong welded mesh panel with small mesh opening. It is extremely difficult to penetrate and difficult to attack using conventional hand tools. Has the features of anti- climbing and anti- cutting. The fence name 358 comes from its panel mesh opening 3' × 0.5' × 8 gauge - approximate to 76.2 mm × 12.7 mm × 4 mm mesh opening.

Galvanized 358 mesh is difficult to be cut, and no fingers hold.

358 mesh fence has the features of anti- cutting and anti- climbing.

358 mesh fence Features:

Anti- climbing: more small openings, no toe or finger holds.

Anti- cut: robust wire and welded joints make cutting very difficult by bolt cutters and wire cutters.

High strength welded at each intersection.

Durable: covering Galfan and polymer powder coating ensure a long service life.

Mesh fencing specially configured to provide maximum visibility, especially used for emergency and electronic detection systems.

Measure 358 mesh size by a ruler, mesh size length 76.2 mm

358 fence panel with mesh size length 76.2 mm

Measure 358 mesh size by a ruler, mesh size height 12.6 mm

358 fence panel with mesh size height 12.6 mm

The panels are made of heavy mesh with a high level of security in width 2515 mm and a height of 2007 mm to 3302 mm. Several panels can be installed on top of each other. Thus may be achieved a total height of 6300 mm.

358 mesh panel size

Mesh pattern: 76.2 mm ( 3' ) × 12.7 mm ( 0.5' ) resistance welded well at each intersection

Wire diameter: 4 mm horizontal wire and vertical Wire.

Weld strength: range 540- 690 N/ m2

Surface treatment: 358 mesh fence panels made from galfan wire, then PVC powder coating ( min. 100 micron) , or PVC powder painting. It provides additional protection and increases the potential life span.

Colours: Green RAL 6005, or Black RAL 9005.

Installation: Overlapped 75 mm minimum at each post ( shown as the two following pictures below) for securing with slotted clamp bars and M8 diameter bolts.

Fence posts

Material: high grade steel for maximum strength and rigidity.

Post section: 80×60 mm, 80×80 mm or 120×60 mm.

Post Plate thickness: 2.5 mm or 3.0 mm.

Finish: inside and outside galvanized ( min. 275 g/ m2) , subsequently covered with a polymer powder ( min. 60 micron ) .

Colors: Green RAL 6005, or Black RAL 9005.

Post cap: 80×60 mm and 120×60 mm post with metal caps, and 80×80 mm post with plastic cap.

Metal clips and clamps are hot dip galvanised then powder coating in green or black color.

Table- 1: 358 MESH FENCE SPECIFICATIONS

Fence height m Panel size ( Height × Width) Fence Post ( Height × Size × Thick ) Clamp Bar ( Height × Width × Thick ) Inter or corner Clamp No ( PCS)

2.0 2007 mm ×2515 mm 2700 mm ×60×60×2.5 mm 2007 mm ×60 mm ×5.00 mm 7 or 14

2.4 2400 mm × 2515 mm 3100 mm×60×60×2.5 mm 2400 mm ×60 mm ×5.00 mm 9 or 18

3.0 2997 mm ×2515 mm 3800 mm×80×80×2.5 mm 2997 mm ×80 mm ×6.00 mm 11 or 22

3.3 3302 mm ×2515 mm 4200 mm×80×80×2.5 mm 3302 mm ×80 mm ×6.00 mm 12 or 24

3.6 3607 mm ×2515 mm 4500 mm×100×60×3.0 mm 3607 mm×100 mm×7.00 mm 13 or 26

3.6 3607 mm ×2515 mm 4500 mm×100×100×3.0 mm 3607 mm×100 mm×7.00 mm 13 or 26

4.2 4204 mm × 2515 mm 5200 mm ×100 ×100 × 4.0 mm 4204 mm ×100 mm × 8.00 mm 15 or 30

4.5 4496 mm × 2515 mm 5500 mm × 100 ×100 × 5.0 mm 4496 mm × 100 mm ×8.00 mm 16 or 32

5.2 5207 mm ×2515 mm 6200 mm×120×120×5.0 mm 5207 mm×100 mm×8.00 mm 18 or 36Green color 358 mesh fence installed - overlapped 75 mm minimum at each post

When install 358 fence on post need overlapped 75 mm minimum at each post

Black 358 mesh panels installed on black post form a strong and security fencing

Black 358 mesh fencing used for protection of residential.

Green 358 mesh panels packaged in plastic film and stored on wooden pallets

358 security mesh panels package

358 high security fences are packaged in plastic film then stored and transported on wooden pallets. Each package is firmly attached to the pallet by a special type tape.

Application: as an anti- climb & anti- cut through barrier, 358 welded wire security fence is designed with maximum security in mind. It is ideally suitable for electronic alarm and detection systems, fencing in prisons, military sites, and airports, industrial and commercial properties, warehouses, power plants, laboratories, secure hospitals, schools, parks, leisure and recreational areas. 358 fence will give them a long lasting and secure perimeter protection with attractive appearance. Generally, 3.60m height fence is used in schools, parks, leisure and recreational areas, 5.20m height fence widely used in prison and military establishments.

2D Security Fencing with 4 mm double horizontal wire and 6 mm vertical wire for greater strength.

This panels increase strength by 6 mm vertical wire and additional 4 mm wires at 152.4 mm centres on the inside face. So it has double horizontal wires at 152.4 mm centres. This structure makes the fence panel very rigid and has a higher level of strength and security than common 358 mesh fence. 2D Security Fencing is widely used for schools, industrial sites, infrastructure, and high security areas.

2D security fencing made form 6 mm vertical wire and has 4 mm double horizontal wires at 152.4 mm centres

Green color powder coating 2D security fencing with 6 mm vertical wire and 4 mm double horizontal wire

2D security fencing panel installed on post in green color

Details of 2D security fencing panel installed on post

2D security fencing Specifications

Mesh opening: 76.2 mm × 12.7 mm welded at each intersection.

Horizontal wires: 4 mm diameter at 12.7 mm centres on the attack face, and intermittent 4 mm double wires at 152.4 mm centres on the inside face.

Vertical wires: 6 mm diameter at 76.2 mm centres.

The post has a single row of M8 threaded inserts which allow the panels to be but fitted with specialised pressed steel brackets and are pitched at 2.55m centres.

Panel width, height, finish, fence post and clamps is the same to 358 mesh fence, please see table- 1.

3D security fencing installation - panel with a V beam and post with a V beam

3D security mesh panel with a V beam installed on a post with a V beam

3D security fence enhanced its appearance with pressed horizontal ' V' shaped beams.

3D security fence is similar to 358 mesh fence, and they are both made from 4.0 mm wire in 12.7×76.2 mm mesh pattern. But 3D security fence enhanced its appearance with pressed horizontal ' V' shaped beams. It is a unique barrier solution which combines a high level of safety and aesthetic appearance. Usually, 3D security fencing is recommended for schools, recreational areas, hospitals, railways, port, airport, warehouses and industrial facilities or commercial.

Table- 2: 3D security fence system specifications

Panels Posts

Fence height Panel Size Height/ Width Number of Beams O/ A Length Material and fixings

Inters Corners

m mm mm

2.0 2000 × 2515 2 2700 80×60×2.0 RHS 6 80×80×2.5 SHS 12

2.4 2400 × 2515 3 3100 80×60×2.0 RHS 7 80×80×2.5 SHS 14

3.0 3000 × 2515 3 3800 80×80×2.5 SHS 10 80×80×2.5 SHS 20A sheet of 3D security fencing panel with V beams in green powder painting

3D security fencing panel

3D mesh panel installed on straight post used for fencing a trees area

3D security fencing offers a high level of safety and aesthetic appearance barrier solution for trees area.


Company Contact:


  • Phone: 8631874682574

  • Address: Industrial Park, Anping County, Hengshui City, Heb, Hengshui, China

  • Email: Email


Published date: June 4, 2014 -

  • Business Description: Choose us, you will get rigid and long life high security fencing

    High security fencing offered by Cenky high security fencing company is an economical way to protect any object with the highest security requirements. Cenky company engaged in supply and installation of professional safety fencing systems. We have been install metal fences barriers over 12 years.

    358 mesh fencing is one of our featured products. In order to increase the security properties, Cenky company also manufactures razor barbed wire, which mounted on 358 welded mesh panels forms more security fencing barrier. Our high security fence are recommended for jails, train stations, military facilities, airport, computer centers, warehouses, distribution centers, power plants, and laboratories.

    In addition to 358 mesh and razor barbed wire, We also manufacture paladin fencing, double wire fence, palisade fencing, and top roll fencing, fence posts and clips. All of our metal fencing meet modern technical requirements, are easy to be mounted with high protective qualities. Our fences have a long life with a ten year guarantee.

    High security fences are stored and delivered on wooden pallets. Packaged in plastic film and firmly attached to the pallet with a special tape.

    Many of our high profile clients have chosen us as their preferred supplier to supply and install fencing where maximum and medium security fencing was required. During the work of our fences have proven reliability and durability. Choose us, you will get high security fencing with the features of low cost, quick installation, high degree of corrosion protection, modern look and long life.

    We are open for cooperation and will be happy to work with private customers and large company, even national government agencies. Contact us, our specialists will help you select the right fencing and calculate the cost of the fence barrier.
