Automatic Door Radar Sensor Md 24 - China

price: contact company for price

Automatic Door Radar Sensor

1. 24.125GHz Microwave Technology

2. CE certificated

Automatic Door Sensor

T E C H N I C A L DATA:

Frequency 24.125 GHz

Supply Voltage 12 to 24 V AC: ± 10%

Mounting Height Maximum: 3M

Assemble a dip Angle: 25°, 30°, 35°, 40°

Detection Area 4m(W) x 2m(D)

Minimum Detection Speed: 5cm/s (measured in axis)

Power Consumption: < 2 W

Max Contact Voltage 42V DC / 60V AC

Max Contact Current 1 A (resistive)

Max Switching Power 30W (DC) / 60VA (AC)

Hold Time 0.5 sec

Temperature Range -20°C to +55 °C

Weight 0.1kg

Material ABS

Protection Rate: IP52

Cable Length: 2.5m only

COLOR Black and Sliver gray


Company Contact:


  • Phone: 8657487925755

  • Address: #8 Shiqi Industrial Park, No.1, Lane 95, Yayuan So, Ningbo, China

  • Email: Email


Published date: June 9, 2013 -

  • Business Description: Ningbo Oudany Automatic Doors Co., Ltd. is one leading manufacturer of

    automatic doors in China, located in Ningbo of Zhejiang Province.

    Main products:

    1. Automatic sliding door operators

    2. Automatic swing door operators

    3. Manual sliding door closers

    4. Revolving doors

    5. Hermetic doors

    6. Automatic door accessories, motion sensor, safety beam sensor etc.

    With specialized teams responsible for R&D, production, quality control, marketing and service, our products are widely used by customers in more than 50 countries and regions.

    We look forward to cooperating with you and providing satisfactory products.
