Halo Equivalent 1000base T Magnetics Modules Single Port Lan Transformer Trc5004nl - China

price: 0.55 Dollar US$

1000Base-T Lan transformer
Single port
Without PoE function
Free sample available
SMD type
Isolation Voltage: 1500vrms
UL, Reach, RoHs, ISO9001: 2008
Free sample supported for testing

1. Designed to support application, such as SOHO (ADSL modems), Lan-on-Motherboard(LOM), hub and switches.
2. Meets IEEE 802.3 specification.
3. Maximum reflow temperature is 260℃, 5 Sec.
4. UL certification: File Number E321120

1.Turn Ratio: ±3%
2. OCL: 350uH Min
@100KHz, 100mV, 8m ADC Bias
3.Insertion Loss:
1-100MHz: -1.0dB max
4.Return Loss(dB Min @ 100Ω):
1-30MHz: -18
40MHz: -18
50MHz: -16
60-80MHz: -12
100MHz: -10
5.Cross Talk(dB Min)
30MHz: -45
60MHz: -40
100MHz: -35
6.DCMR(dB min):
30MHz: -43
60MHz: -37
100MHz: -33
7. Isolation Voltage: 1500Vrms min
8. Operating Temperature: 0 to 70℃

Company Contact:

  • Phone: 86--13554918626

  • Address: 4/F,3 BLDG,No.3 Industrial Zone,Minzhi Villiage,Longhua Town,, shenzhen, Guangdong , China

  • Email: Email

Published date: August 23, 2016 -

  • Business Description: Trxcom is the leading manufacturer of RJ45 connector with magnetic,Lan Transformer, Audio transformer.

    The products are widely used in networking and communication equipments such as HUB,PC card, Switch, Route, PC Mainboard, SDH, PDH, IP Phone, Xdsl Modem.
    1) 10/100/1000M LAN pulse transformer and filter
    2) RJ45 connector with 10/100/1000M magnetic
    3) T1/E1, T3/DS3/E3.STS-1 interface line transformer
    4) ISDN, HDSL, ADSL and VDSL interface line transformer and splitter
