N Female Gold Plated Crimp Panel Receptacle Connector - China

price: contact company for price

Material:

- body: Zinc alloy gold plated

- pin contact: Bass

- insulator: POM

Specifications:

-Impedance : 50 ohm

Frequency Range: DC ~11 GHz

Voltage Rating: 1, 500 volts peak

VSWR straight connectors: 1.3 max 0-11 GHz

Right angle connectors: 1.35 max 0-11 GHz

Dielectric Withstanding Voltage: 2, 500 volts

RMS

Insulation Resistance: 5, 000 ohm; Minimum

Center Contact Resistance: 1.0 m ohm

Outer Contact Resistance: 0.2 m ohm

Insertion Loss: 0.15 dB maximum at 10 GHz

Durability: 500 max cycles


Company Contact:


  • Phone: 18819517326

  • Address: Floor Five and Six,Huihuang Hi-Tech Park No.19 Roa, dongguan, China

  • Email: Email


Published date: December 3, 2014 -

  • Business Description: Dongguan Dosin Hardware Electronics Co., Ltd. is a professional

    manufacturer, engaged in the research and development, production, sale and service of RF coaxial connectors and other related products. Ourcompany is located in Xiabian, Changan Town, Dongguan City, Guangdong Province of China, now it covers an area of 3000 square meters.

    Our main products are BNC,TNC,PAL ,SMA,F,SSMB,MMCX, 1.6~5.6 AND 1.0~2.3 Coaxial series ,cables assemblies , etc. which is generally used in communication products,broadcast,wireless video surveillance ,HD video dispay products etc.

    Based on our strong technology support , we can design and manufacture connectors according to customers ' special requirements . We have been insisting on taking quality,service,reputation,thanksgiving,as the basis of our survival and development .All company staffs are full of confidence to offer high quality , reasonably priced products and honesty services at any moment.
