Tp03ab220s12w 3w 3kvac Isolation Wide Input Acdc Converters - China

with wide input voltage range, for both AC input and DC input application.

High reliability, precision, large power density, ultra-small size, no external heat sink required, stable output voltage and etc, with over current protection, EMI filter circuit, the rectifier filter circuit, 3000V isolation voltage, short circuit, overload, internal thermal protection, Widely used in industrial control, telecommunications, instrument, data acquisition, signal control and other electronic systems.

Part Number Input Voltage Output Efficiency (Typ.

)

% Voltage Voltage (VDC) Current(A) Voltage (VAC) Voltage(VDC) TP03AB220S03W 85-265 120-370 3.3 0.60 64

TP03AB220S05W 85-265 120-370 5 0.60 68

TP03AB220S09W 85-265 120-370 9 0.33 70

TP03AB220S12W 85-265 120-370 12 0.25 72

TP03AB220S15W 90-264 120-370 15 0.20 76

TP04AB220S03W 90-264 120-370 3.3 0.80 64

TP04AB220S05W 90-264 120-370 5 0.80 68

TP04AB220S09W 90-264 120-370 9 0.44 70

TP04AB220S12W 90-264 120-370 12 0.33 74

TP04AB220S15W 90-264 120-370 15 0.266 76

Company Contact:

• Posted By: TOPPOWER

• Phone: 862062162688-809

• Address: Building No.3 ,Rui Fa Road No.15,, Guangzhou , Guangdong , China

• Email:

• Website: https://en.gztoppower.com

• Business Description: Toppower is a professional manufacturing enterprise of DC DC converters.

  We focus on miniature DC DC converters researches, produces and markets,

  Our products have been used in many fields; such as: Industrial Control

  System, Power system, Apparatus and Instrument, Medical facilities, Rail

  transit system, Telecommunication Equipment, Security and Protection

  Equipment and Military Industrial System etc.

  Toppower owns an outstanding researching team.

  The products are 100% inspected and tested automatically by the advanced testing equipment.

  The unique product design, manufacturing process and equipment make our products with high efficiency and very good reliabilities.

  All DC DC converters are made with high quality spare parts and UL 94V 0 package material from the international prestigious suppliers.

  As well, the products meet ROHS requirement and covers 40+ series with thousands of variants from 1 to 50W for your choice.

  Our team targets to support you with professional products and service.

  We also have stocks for the popular variants so as to meet your emergency needs on time.

  we,TOPPOWER can produce:

  0.1W-400W DC-DC converters,1W-30W AC-DC converters,(SIP/DIP/SMD)

  15W-1200W Enclosed /Open frame/DIN RAIL type AC-DC Switching Power supply,

  TOPPOWER quality : ISO9001: 2015, IATF16949: 2016

  Guangzhou Top Power electronics Technology Co., Ltd
