Hab 80 Ais Fishing Net Tracking Buoy - China

price: contact company for price

HAB- 80 AIS Fishing Net Tracking Buoy

FEATURE:

Long time battery, more than 240 hours each time Smart GPS antenna module allows an excellent GPS signal receiving Stable and reliable RF performance High- level waterproofing protection up to IPX7 Self developed AIS Fishing Net Tracking Buoy, allows you to get an accurate location at night, in rain, and fog.

Proved Performance

Up to 10nm from a ship with AIS A or B transponder

Application

Wanting for an accurate location of your fishing net? Wanting to save your time and fuel to find your net? Self developed AIS Fishing Net Tracking Buoy, allows you to get an accurate location at night, in rain, and fog. Don’t worry about losing your fishing net anymore!

HAB- 80 AIS Fishing Net Tracking Buoy unit uses advanced AIS technology to transmit the combined data that include the unique ID and the position of a net. And the data can be received effectively by the vessel equipped with AIS device, then easily recognized and find back the nets with HAB- 80. Also it can avoid collision accidents by other boats.

Specification

Standards:

EC62287- 1: 2006- 03 IEC60945: 2002 ITU- R M. 1371- 2

Position update: every 3 minutes

Working frequency: 161.975MHz / 162.025MHz

Output power: 34.8dBm±1.5dBm

Channel bandwidth: 25 KHz

Modulation mode: GMSK

Bit Rate: 9600b/ s±50ppm( GMSK)

Dimension: 330 mm x 90mm

Weight: 0.5 KGS

Battery: 8.4V, 4000mAh; rechargeable

Working time: More than 240 hours

Antenna: Built- in VHF/ GPS antenna

GPS Module: IEC61108- 1 standard

Working Environment: - 20C – 55C

Waterproofing: IPX7

Equipment List:

HAB- 80 Tracking Buoy unit Battery recharger


Company Contact:


  • Phone: 8675583289123

  • Address: Unit 601,Bldg#614,Bagualing Industry Area,Futian D, Shenzhen, China

  • Email: Email


Published date: October 29, 2015 -

  • Business Description: Huayang Technology (HK) Co., Ltd. is a professional marine electronics

    company, we have professional sales team and quality products equipment,

    the spirit of "innovation and development, integrity based " corporate

    philosophy, strive to create a first Service platform.

    Huayang Technology products include Marine Radar , GPS navigation, fish finder, GPS chart plotter , ECS , ECDIS , Auto Pilot , AIS , AIS Sart , Radar Sart , Satellite phone of Inmarsat , Satellite phone of Iridium , Dock station for Inmarsat Isatphone pro , etc . Our products are mainly exported to Southeast Asia, North America and South America , and Middle Eest market . Through 10 years of development, the company already has an R & D team of 20 people, and to the continuous development and innovation for our customers to develop more advanced navigational equipment.

    Hua Yang Technology in the "innovation and development, good faith"concept, together with domestic and foreign counterparts in the field of marine electronic equipment continue to forge ahead, and dedication to provide the most complete marine electronics.
