Small Wdr 700tvl Low Lux Mini Osd Box Camera 40x40x54mm Cm Spv Y44q P - China

price: contact company for price

Model No. : CM-SPV-Y44Q-P

Lens No. : JC/2.8A

Features :

1. Mini OSD Box Camera

2. Various CCD option

3. Sony Effio-E / Effio-P, Nextchip solution available

4. Various C/CS lenses option, with DC drive input

5. 420 - 700TVL option

6. 0.01 0.5Lux option.

7. WDR / BLC/ NDR / etc available

8. Defog / Mirror, etc available

9. Power: DC12V, DC5-15V

10. Suitable for indoor surveillance

11. OSD Menu adjust functions

12. Housing Size: 40x40x54mm

13. Patented design

Model CM-SPV-Y44Q-P

Image Sensor 1/3 960H Sony Double Scan Super HAD CCD II

Number Of Pixels PAL: 976(H)*582(V) NTSC: 976(H)*494(V)

Horizontal Resolution 700TVL

Illumination 0.01LUX / F2.0


OSD Support

Sync System Internal Synchronization

AGC Adjustable

BLC Adjustable

Audio Output 300mV at 600 Oms

Video Output 1Vp-p 75 Oms, Negative

S/N Ratio More Than 50dB (AGC off)

Electronic Shutter Adjustable

White Balance Adjustable

Motion Detection Adjustable

Mask Adjustable

DNR 3D DNR (Digital Noise Reducer)

E-Zoom Adjustable

Gamma Character 0.45

Scanning System PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec

Frame Accumulate Adjustable

Language English, Chinese, Japanese

Anti-shake Support

Day & Night Adjustable

Mirror Adjustable

Power Consumption 5~15V± 10%DC, 260~90mA
