Arm7 Mcu Hf 13 56mhz Rfid Desktop Reader And Writer With Usb Pc Sc Interface Mr810 - China

MR810 series, based on NXP PCD, are the USB PC/ SC interface smart

reader.

The reader supports series IC cards according to ISO14443A,

ISO14443B, ISO15693 and ISO7816; various contactless IC card under

international standard; especially the contactless CPU cards under ISO14443-

4 - Meanwhile the reader is available to pass EMV2000 and PBOC 2.0 and be

authenticated by many laboratorial certifications- - - Visa Wave & Pay

Pass ( by FIME) and the Bank Card Test Center.

There are 2 SAM card

slots in the reader which support SAM cards compliant with ISO7816 ( T=0

and T=1) .

The reader supports card- reset of various communication

rate; PPSS operation after card- reset; SAM operation of various

communication rate.

Qualifications:

PCD: NXP RC531, RC632 , RC400 , RC500

Working frequency: 13.56MHz

RF standard: ISO14443A, ISO14443B, ISO15693

Operating distance: 100mm ( MIFARE One, typical distance)

SAM card slot: 2 slots, ( supports ISO7816 T=0 and T=1)

Interface: USB PC/ SC

Power supply: DC5V ± 10%

Power consumption: 0.9W

Dimension: 123mm×88mm×25mm

Weight: about 100g

Operating temperature: - 25 ~ +85 ℃ ( - 77 ~ +185°F)

Storage temperature: - 40 ~ +125 ℃ ( - 104 ~ +257°F)

PC software: PTransWin

SDK& Program: VC, VB, C++ Builder, DELPHI, Power Builder

Company Contact:

• Posted By: Jinmuyu Electronics Co., Ltd

• Phone: 861069559637

• Address: Room 132, Building 16, Tian Qiao Wan, XinHua North, Beijing , China

• Email:

• Website: https://www.jinmuyu.com

• Business Description: Jinmuyu is one of the leading 13.56MHz RFID reader manufacturers.

  We

  build, design and customize products to satisfy a range of customers.

  Our production facilities are certified under ISO/IEC10373 6, EMV2000,

  EMV2010 and PBOC 2.0 which are recognized all over the world.

  Our

  products support ISO/IEC14443A, 14443B, 15693 and ISO7816(T=0, 1)

  protocols and also support MIFARE 1K, MIFARE 4K, FM11RF08 C, MIFARE

  Mini, DESFire, MIFARE Plus; CPU cards(Type A/B, dual Interface, T=CL);

  SR176, SRI512, SRI1K, SRI2K, SRI4K, SRIX4K, AT88RF020; NXP I.

  CODE SLI,

  TI Tag_it HF I, ST LRI and so on.

  The products contain JMY620 series which are the surface mounted design, can send and receive more than 256 Bytes APDU commands and also support FSDI=8; lower power consumption like JMY504; JMY601 (Integration antenna design); JMY501 (connection outside antenna via four lines); JMY505 (connection outside antenna via 50ohm coaxial cable); JMY680 (applies to some metallic around systems); MR800 (with LCD display); MR600 (inlay LED Nixie tube which with 8 bits LED display); the ID reader MR761 series which can support positive sequence, reverse output in hexadecimal or decimal UID, and can read the data in the card via configuration.

  Many of the above products contain one or more than one SAM card slots.

  At the same time, the interfaces for the reader we can offer IIC, UART, RS232C, RS485, USB (HID or PC/SC standard), Ethernet RJ45 (TCP/IP), Bluetooth and so on; and the PCD contain NXP RC500, RC531, RC632, RC400, RC522, PN512, RC523, FM1702, FM1712, FM1722; Meanwhile in order to meet the different needs of different users, we use MCU 8051, ARM7, ARM9 and ARM11 to develop the module or reader.

  It is worth mentioning that we also provide ODM / OEM customized products and services.

  Welcome to contact us, and we will provide you with the high quality products and the excellent services.
