Stepper Motor Controllers Drill Cycle Controller - India

price: contact company for price

DRILL CONTROLLER

Tiny Controls’ Drill Controller is a new concept for drilling operations. It is an economical solution designed to automate the repetitive drilling tasks.

Two setups named Msetup and Rsetup are provided in the system. Msetup ( Main setup) controls the motion parameters of stepper motor and Rsetup ( Run set up)

controls the drilling speed, depth of drill and number of steps in one drill round.

Specifications and Features:

1. A 20x4 alphanumeric LCD to display status and settings.

2. Easy to understand menus and smooth navigation.

3. 16 bit controller with 32 bit math for precise indexing.

4. Maximum Pulse rate: 40 KHz.

5. Control:

a. Jogging.

b. Longitudinal speed control.

6. Inputs: 3 NPN Proxy ( Msetup, Msetup and Home) + 1 On- Off switch for start- stop.

7. Outputs: 2 ( Step and Direction) for motor +two 12V outputs ( for NPN proximity type sensor) + 5V output.

8. Operating interface: User friendly keys.

9. Panel mounting.


Company Contact:


  • Phone: 09911193210

  • Address: C 55, Nishat Park Kakrola, New Delhi, India

  • Email: Email


Published date: January 7, 2015 -

  • Business Description: we are working since 2011 in the automation field with the aim to

    provide the best quality automation products matching the current

    standards of CNC industry at reasonable costs. we are the supliers of

    stepper motors and high speed spindle motors and are the manufacturer of

    stepper motor drivers, CNC breakout boards, C

    USB cnc Controllers, cable drag chains, reduction gear assemblies, power supplies, stepper motor controllers, spindle mounts, stepper pulse generators, CNC controllers, Mach3 CNC controllers
