Fc T24 High Speed Annealing Tinning Machine - China

price: 24333.00 Dollar US$

FUCHUAN ® Normal wire high speed annealing machine
Characteristics:
Easy to operate, good annealing heat preservation, save electricity, achieve industry-leading level.
Equipment models FC-T12 FC-T16 FC-T24 FC-T32 FC-T40
Twisting usage Apply for the annealing of ultra-fine round copper wire and alloy wire.
Single wire dia(mm) 0.08~0.25mm/0.15~0.64mm
Max numbers of inlet wire 12 16 24 32 40
Linear speed MAX:300m/min
Pay off method Brush pay off
Pay off bobbin model 300bobbin
Annealing furnace length 3.5m-6.0m
Annealing method Tube annealing
Annealing protection method Water seal protection
Tinned method Hot dip
Capstan control method Inverter+ motor control or adopt stepless speed regulation motor
Equipment total power 51KW 53KW 61KW 63KW 68KW
Take up control Take up is voltage regulator control the moment motor
Take up bobbin size 5inch, 8inch bobbin or 5inch, 8inch, 10inch bobbin, 300 bobbin
Traverse control method Stepless speed regulation motor+ turbine gear box control toothrow traverse
Installation size (mm) 13000*1500*2100 14500*1500*2100 18000*1500*2100 20000*1500*2100 24000*2200*2100


Company Contact:


  • Phone: +8615806265585

  • Address: No18.Leigongjing road,huaqiao town, kunshan city, Jiangsu, China

  • Email: Email


Published date: August 2, 2016 -

  • Business Description: Mainly produce wire bunching machine,wire extrusion machine,wire annealing tinning machine and so on for 15years.
