Simple Lift Type Two Three Layers 65288 One Layer Of Pit 65289 - China

price: contact company for price

Main components:steel structure;pallet;driving

system; control system;safety protection device。

Technical description: ① The pit must be armoured

concrete structure to fix the equipment,column and expansion

bolt; ② The pit must be treated as

waterproof,and sump must be set for the water draining;

③ The depth of the pit of two layers should be no less than

2700mm,three layers should be no less than 4450mm, this is

the net size from ground to the bottom of pit; ④ The

location of device should be equipped with enough power supply。

Characteristics of equipment: ① Save ground and take full

use of the underground space; ② It can achieve multi-units

together to raise more parking numbers; ③ Easy operation of

automatic control system; ④ Multi-protection-systems enable

people and machine safe; ⑤ The bottom or the middle and

bottom layers have functions of anti-dust,anti-rain and anti-

theft; ⑥ The equipment is suitable for the place which

demands high lighting and ventilation。 Working principle:

This parking system is designed that all the spaces as one

unit。Three layers of top ,bottom or top ,middle and

bottom are united and lifted together。Usually,the top

layer is in the same line with the ground for cars parking or retrieving

directly。The bottom or middle and bottom spaces may be parked in

or out after being lifted。

Simple Lift Type Two Three Layers 65288 One Layer Of Pit 65289

Feel free to contact us with all your questions

Company Contact:

  • Phone: 0086-532-84829888

  • Address: No.3 Zunyi Road, Qingdao, China

  • Email: Email

Published date: November 1, 2012 -

  • Business Description: Qingdao Haoyue Machinery CO., Ltd. set up mechanical parking equipment division in 2006, meanwhile qualified the state certificate license, and passed ISO9001 quality certificate.
    Haoyue is the first set of design, production, sales, installation, service in one of the stereo garage factory in Qingdao. Haoyue stereo garage division has three processing shop, a paint shop and a distribution box with H type steel automatic welding machine, NC flame plasma cutting machine, NC shearing machine, NC bending machine, large stamping equipment, shot blasting machine and other advanced production processing equipment, has a large number of experienced engineers and skilled technicians to research、programme、manufacture、install and maintain, has a mature technology of all kinds of three dimensional parking equipment, such as lift sliding parking equipment and the simple lifting parking equipment.
    Tiny place, infinite space! With more than 40 years manufacturing experience, we are sincerely looking forward to customers' cooperation and build our brilliant future together!
