Water Cooling Spring End Grinder - China

1 - The Water Cooling Spring End Grinder with CNC control system also

called Water Cooling Spring End Wet Grinding machine or liquid spring

grinder is researched by Wintime Machinery Co.

, Ltd for heavy duty

springs or big springs grinding and milling .

2 - Feed speed can be set to keep the end from being grinded over.

High work efficiency.

Servo motor and ball screw feed .

Bar material installed easily.

Bar material W.

D is Φ 10—Φ 70 mm& O.

D is Φ 80—Φ 500 mm& Spring Length is 1100 mm .

Max grinding wheel size is Φ 900 mm（ 36``） and can be custom- designed .

2 pieces heavy duty springs like locomotive cylindrical spiral spring 、 bolster springs or 4 pieces small springs like car springs or leaf springs are available at the same time.
