Differential Pressure Controller

Model: CJZK-06

Description:

CJZK-06 intergrades with meassure, display and controlling.

It utlizes high accuracy differential pressure sensor as testing component.

It with circuit generation is high stable and realises continous measuring and switch controlling Specification: Measure Range: 0-10, 351000Kpa 0-2---3.5Mpa

Overload Pressure: ≤150%FS

Pressure Type: Differential Measure Media: gas or liquid compatible with 316L stainless steel

Output Signal: 2 sets of switch signals

4-20mA standard signal output (optional)

Relay Load: 30V/5A DC 240V/3A AC

Power Supply: 24VDC/220VAC

Accuracy: ±0.3%F.

S ±0.5%F.

S

Pressure Port: M20×1.5 G1/2 or customize

Long-term Stability: ≤±0.3%F.

S/year

Media Temperature: -20℃～85℃ Response Time: ≤1ms

Load Impedence: R= (U-2.5)/0.02- Ro, U is power supply, Ro is internal resistance of wire

Life time: >1* 10^8 pressure circulation

Diaphragm Material: 316L stainless steel

Case Material: 1Cr18Ni9Ti

Electrical Connection: Connecting Terminal

Protection Level: IP65
