Electrodynamic Modal And Vibration Shakers - China

electrodynamic modal and vibration shakers

Instrument Introduction :

Three integrated chamber known as: three integrated temperature and humidity chamber vibration , three comprehensive testing machine, composite environmental chambers , combined with the detection of conditions of temperature, humidity, and vibration for aerospace products , information and electronic instrumentation, materials , electrical , electronic products, all kinds of electronic vitality test its performance indicators at each temperature , humidity, vibration environments.

Technical parameters:

1 - exciting force: sine 3000N; random 2400N

2 - Frequency range: 5Hz ~ 4000Hz do fixed-frequency , round sweep , sine , random waves.

3 - Sweep mode: linear , logarithmic , positive and negative sweep, fixed frequency .

4 - sweep Views: 1-32767 times.

5 - Sweep time: fixed frequency/single sweep of 1-3600min, and can display a variety of sweeping curves.

6 - Maximum acceleration: 1000m/s2 (100 G, no load )

7 - Maximum speed: 1.6m/s

8 - Maximum Displacement: 25mmp-p (.

Unloaded ) double peak .

9 - effective mass vibration components: Dynamic Weight 3.0kg

10 - Maximum load: 120kg

11 - vibration direction: Vertical + Horizontal

Main Chassis:

1 - with bulkhead connectors , you can connect and shaker

2 - No fog observation window and interior lighting products to facilitate clear observation

3 - sample chamber port and all-welded frame , eliminating potential leak problem , extended equipment life

4 - inner chamber made of 304 polished stainless steel, easy to clean.

A fully welded seams way , sealing to prevent moisture from entering the chamber

5 - chamber wall using pressure plate, greater structural strength , using durable powder/polyurethane coating process ( specified by the user can be sprayed coating )
