Lightning Stoke System For Direct Current Test On Aircraft - China

price: contact company for price

Application

The lightning stoke system for direct current test on aircraft comprises of three sets of impulse generators and one set DC power source, which can generate A, B, C, D four current components to meet the direct effect requirement on aircraft.

The test system has four control systems which can not only be operated separately but also can be synchronously controlled by one human interface if necessary.

The test system is also applicable for other research test such as OPGW in power system

Standard

IEC60060- 1, IEC60060- 2, IEC61312, Mil- Std- 464C

System Configuration

 Switchgear Cubic for AC power system 400V, 50/ 60 Hz

 GIC200C Impulse Current Generator with Crowbar Unit ( component A)

 GRIC20- 5 Square Waveform Current Generator ( component B)

 GZL- 800L DC Power Source with Battery ( Component C)

 GIC100C Impulse Current Generator with Crowbar Unit ( Component D)

 Accessories for the system, cables, tools, fuses, inductors, resistors‚Ķ

 Calibration certificate of measuring system from XIHARI

Technical Specification

Direct Lightning Current Model No Shapes Peak Current Remark

Component A GIC200C 10/ 350μ s 200kA Crowbar circuit

8/ 20μ s 250 kA

Component B GRIC20- 5 Td=2ms 5kA Long duration

Component C GZL- 800L Direct current 800A

Component D GIC100C 10/ 350μ s 100kA Crowbar circuit

8/ 20μ s 200kA


Company Contact:


  • Phone: 8621346955008019

  • Address: Office No.413, Pole Tower, No.425 Yishan Road, Xuh, Shanghai , China

  • Email: Email


Published date: November 14, 2014 -

  • Business Description: involved in international trade import export of goods, products, and services
