Scope

This instrument can be used to determine the absolute viscosity of Newton liquid.

Widely used in oil, paint, pulp, textile, food, medicine, adhesives, cosmetics and other production industries and research units.

The instrument has the advantages of accurate, rapid, intuitive and simple measurement, and it can be used in various industries.

Features

1, this instrument uses the LCD display, the key mark is clear, the procedure design, the operation is simple

2, the instrument uses a 16 bit microcomputer processor as the core of the stepper motor with high breakdown drive, stable speed, accurate

3, this instrument adopts the procedure design, the operation is simple and convenient, the alarm function, the screen directly shows the viscosity, the rotational speed, the percentage of the torque, the rotor number

4, the temperature measurement range of the instrument is -20 C -100 C, wide temperature range detection.

5, the main control board of the instrument, the subdivision driver board all use the patch technology, circuit design using the current most advanced microcomputer processor, reasonable and compact structure layout.

The instrument has a full range, all of the linearity of the measurement calibration through the PC interface, its measurement performance and function to achieve the same type of domestic advanced level.

Technical Parameters

1 - Measuring range: 1—2000, 000 cp, If less than 20cp, you need to select the 0#rotor

2 - Unit conversion: 1pa.

s = 1000 mpa.

s, 1pa = 100mpa.

s, 1mpa.

s = 1 cp

3 - Spinning speed: 0.3, 0.6, 1.5, 3, 6, 12, 30, 60, eight kinds of speed control, automatic adjustment, imported motor

4 - Measuring range Display: The instrument can automatically display the measurable maximum viscosity value of the combination of rotor and rotating speed.

5 - Scan function: According to the viscosity value of the test samples, the machine can be automatically prompted to give the best combination of the rotor speed

6 - Number of rotors: Random configuration No.

1 3, 2, and 4 four kinds of rotor

7 - Peripheral Interface: a R232C communication interface, a temperature probe interface, a power jack

8 - Measurement accuracy: ≤ ± 2.0% (Newtonian liquid)

9 - Reproducibility: ± 0.5%

10 - Power supply: 110V-230V, 50HZ / 60HZ
