Continuous Slot Wire Wrapped Water Well Screens - China
price: 22.00 Dollar US$
Continuous slot wire wrapped water well screens are manufactured by a v or wedge shaped wire around an internal array of longitudinal support rods.
Each intersecting point of these wire is fusion welded.
The v or wedge shaped profile wire wraps around the support rods over the full length of the screen creating a continuous slot opening, hence the screen allows water (oil) to enter your well freely in ample quantities, while at the same time keeps the majority of sand and gravel out of the well.
Specifications of Continuous slot wire wrapped water well screens
1 - Slot size(mm): 0.1~3mm
2 - Open area: up to 60%
3 - Material: low carbon, low carbon galvanized steel (LCG) steel treated with anticorrosion coating, stainless steel (304, 316L etc)
4 - Unit Length up to 6 meters
5 - Diameter: ranging from 25 to 800mm
6 - End connection: plain beveled ends for butt welding or threaded coupling or flange
Company Contact:
- Posted By: Oasis Oil Tools Co.,Ltd
- Phone: +86-373-2947626
- Address: Xuanhe West Road,Fengquan District, Xinxiang , Henan , China
- Email:
- Website: https://www.oasiswellscreens.com
Published date: October 30, 2018
- Business Description: Oasis Oil Tools Co., Ltd is a professional manufacturer of water well screens, Johnson screens, wire wrapped well screens, continuous slot vee shaped wire well screens, wedge wire screens , oil well screens, bridge slotted well screens, rod based well screens, pipe based well screens, API casing, ISO tubing, steel pipe, steel tube.
