Tls 600 Rotary Vibrating Screen - China

price: contact company for price

Supply TL vibrating screen , Rotary vibrating screen , Circular vibrating

screen , Ultrasonic vibrating screen , Linear vibrating sieve and other

kinds of vibrating sieve , Complete product specfication , and quality

confirmation .

TLS SERIES ROTARY VIBRATING SCREEN :

The basic principle of the vibrating screen is the use of weight on the shaft of the motor installed under the (unbalanced weight), the rotary motion of the motor into horizontal, vertical, inclined three dimensional motion, then this movement is transferred to the screen surface, so that the material be extended involute motion on the screen surface, so that the series of vibration known as the rotary vibration sieve sieve. Rotary vibration sieve with material of running track length, screen efficiency advantages, phase adjustment, the lower ends of the angle of hammer, can change the material in the sieve surface trajectories. Can fine sieving, grading of material probability screen.

Rotary vibrating screen introduction

TLS series of rotary vibration sieve is a kind of high precision powder screening machine, and its low noise, high efficiency, need only 3 - 5 minutes quick network, fully enclosed structure used for sieving filter particle, powder, mucus and other materials.

Rotary vibrating screen character :

☆ the machine adopts special high-performance vertical vibration motor, to provide you with the surging momentum, support for long time and uninterrupted work. The contact part in in in in in can body and the materials used in all grade stainless steel plate, health, sterile, corrosion resistance, wear resistance is superior.

☆ Tianlong vibrating screen uses V type unique enhanced the locking bundle ring and special structure, safer, more secure.

☆ screen is the tension and the network technology used in some of the most sophisticated in the industry, greatly improve the effective area of the screen, with the screening precision high, the yield has been increased further.

☆ convenient cleaning, mesh without congestion, and can be repeated continuous use, changing network faster and more convenient, only 3-5 minutes.

☆ wide application range, food, beverage, pharmaceutical, chemical, plastics, abrasives, ceramics, papermaking, nano-materials industries classification, except the ideal equipment for impurity, mixing, compaction and filtering, solid-liquid separation.

Rotary vibrating screen dimension:

model Diameter(mm) Diameter of the screen(mm) Effective sieving area(m²) Diameter of the material(mm) Screen size (mesh) Layer(s) Rpm Power(KW)Vibration motor

TL-400 400 340 0.09 <10 2-325 1-3 1500 0.18

TL-600 600 530 0.22 <10 1500 0.25

TL-800 800 720 0.4 <20 1500 0.55

TL-1000 1000 900 0.63 <20 1500 0.75

TL-1200 1200 1100 0.95 <20 1500 1.1

TL-1500 1500 1400 1.5 <20 1500 2.2

TL-1800 1800 1710 2.3 <30 1500 3

TL-2000 2000 1910 2.86 <30 1500 4

Rotary vibrating screen apply for the industry :

Screening filter any powder, particle, mucilage class.

food industry, flour, milk powder, sugar powder -, salt, soybean milk, egg powder, starch, dextrin, condiments, juice, beverage, rice noodles, soy, yeast extract, pineapple juice, fish meal.

chemical industry - resin powder, paint, industrial chemicals, cosmetics, paints, powder, PVC resin powder, citric acid, polyethylene powder, washing powder.

metal, aluminum powder, lead powder, metallurgical mining - ore, copper, alloy powder, welding rod powder, manganese dioxide, electrolytic copper powder, magnetic materials, abrasive powder, refractories, alumina, kaolin, lime, calcium carbonate, Ishi Eisa.

pharmaceutical industry - traditional Chinese medicine powder, liquid medicine, western medicine, pharmaceutical intermediates and other liquid.

abrasive ceramic metallurgical industry - quartz sand, mud, kaolin, alumina, aluminum, artificial black spray particle, silicon carbide, corundum, iron, lead, titanium dioxide etc..

pollution treatment - waste oil, wastewater, dyeing wastewater, additives, activated carbon.

Rotary vibrating screen character and advantage :

Composite type, stamping truss design, 3 - 5 minutes of screen replacement can be completed, change a network 2 can, the whole screen, long life, low energy consumption, low cost of repair. The three dimension vibration of XH three yuan rotary-screen vibration source, strong and smooth, the device can be mounted to any desired location and convenient movement.

Rotary vibration sieve screening range

three dimension vibration sieve screening: any particle, powder, mucus within a certain range can be screened. Most fine sieve to 500 or O028rrlm, the smallest filter to 5 microns. Screening, screening with one to five layers of screen mesh, sorting or filtering can also undergo two to six grade.

Rotary vibration sieve screening of high precision:

Fully closed structure, no dust, powder, the liquid does not leak, the mesh is not blocked, automatic discharge, no deposit material in the machine, the network structure without dead angle, the screen area increased.

TLS series of rotary vibration sieve main features:

1 high efficiency, design is exquisite and durable, any powder, mucilage are screening.

2 screen changing, simple operation, convenient cleaning easier.

3 the mesh is not blocked, no dust, powder sieve to 500 or 0.028mm.

4 impurity, coarse material automatically, can continuously work.

5 unique grid design, screen for long time use, fast network for only 3-5 minutes.

6 small volume, does not occupy a space convenient movement.

7 screen machine can reach five of the maximum layer, recommend the use of three layer. And machine selection preferably not more than TLS-1500.

Henan Tianlong Machinery Manufacturing Co., Ltd. is a professional production of vibration screening equipment manufacturers, we can according to the actual needs of customers, in accordance with customer requirements, produce the most consistent with vibration sieve, and provide perfect after sale service! Let you buy the rest assured, with the comfortable, solve customers any menace from the 'rear'!

Connection

ATTN MISS JANE

MOBILE 0086-15736953408

TEL 0086-373-3350555 3350558

FAX 0086-373-3350558

WEBSITE WWW.XXTLJX.COM

Product service commitment:

1 machine warranty for one year, three years, life-long repair (except the spare parts). 2. of the whole year if the quality of the new replacement machine.

3 factory using tools from random distribution equipment related to a number, wearing parts.

4 if necessary, we cooperate with work, I can be rushed to the scene to provide service in 24 hours.

5 we sent into the factory free installation and debugging, debugging after passing the factory use.

6 to our tracking equipment use, can discover problems and solve the problem in the first time.

Henan Tianlong Machinery Manufacturing Co. Ltd. will uphold the service commitments, if you have any questions, please contact, the final interpretation of the company.


Company Contact:


  • Phone: 00863733350555

  • Address: no.101 xima road, , xinxiang ,, China

  • Email: Email


Published date: May 13, 2013 -

  • Business Description: Xinxiang Tianlong Group, a military enterprise combined with scientific

    research, production and service and a Group of production and

    operation, relies on sophisticated equipment of military enterprises,

    technical personnel of high quality, scientific management and strict

    warranty product system. Now it has became specialized in exportation

    and products of six series such as non standard sprocket, gear and

    transmission, vibration screen, transportation machinery and food

    filtration machinery, as well as specifications over 80 sorts. The

    products have passed ISO9002 Quality System and Certificates since 1996

    and ISO9001: 2000 Quality System and Certificates since 2004.

    Tianlong Group presides over import and export trade companies, product marketing Corporation, product selling Corporation, sprocket and gear factory, and vibration equipment factory.

    The sprocket and gear factory manufactures non standard roller sprocket, non standard teeth sprocket, non standard gear, non standard steel set and various types of standard sprocket and standard profiled transmission case, all of which are produced by advanced designing methods like CAD, CAM and advanced heat treatment techniques. All these products accord with the standards of ISO, ANSI, DIN, BS and so forth. They have been exported to many countries and regions such as Europe, U.S., and Germany and so on. Besides, our annual output is more than two million pieces.

    The series of vibration equipments, upgrade equipments, conveyor equipments and filter equipments produced by vibration equipment factory are all produced by advanced designs and manufacturing technology in order to ensure the quality of products. It develops complete sets of equipments such as rotary vibration sieve, linear shaker, air sifter, cyclone screen, efficient heavy screen, vibrating hopper, vibrating feeder, belt conveyor, bucket elevator, vibration mill, vibrating and deslagging filter and silo wall vibrator etc. with high tech.

    We uphold the business philosophy of Solidity, Practicality, Honesty and Efficiency, and we build our prominent brand with high quality product and excellent service.

    With various high quality products, prompt service and reasonable price we not only strengthen our old clients but also develop new ones. Tianlong people welcome you coming to negotiate with open arms!
