Two different size stainless steel wedge wire filter tubes and one galvanized wedge wire filter elementProduct Introduction

Wedge wire filter element also named wedge wire screen is made of V- shape profile wire and longitudinal support rods.

Each intersecting point of these wires is fusion welded which makes it has sturdy construction and good mechanical property.

The profile wire and support rod can be axial wire or radial wire.

It mainly includes internal filtration, external direction filtration.

According to the different usage, we can design the flow direction and shape to meet the application requirements.

What’s more, we can customized the wedge wire filter element such as filter tube, filter basket based on the clients requirements.

Specification:

Material: low carbon galvanized wire, mild steel wire, stainless steel wire ( SS302, SS304, SS304L, SS316, SS316L, etc.

)

Wedge wire

Width: 1.50mm, 1.80mm, 2.30mm, 3.00mm, 3.70mm, 3.30mm.

Height: 2.20mm, 2.50mm, 2.70mm, 3.60mm, 4.30mm 4.70mm, 5.60mm, 6.30mm, 7.00mm.

Support wire:

Support rod:

Width: 2.30mm, 3.00mm, 3.30mm, 3.70mm.

Height: 2.70, 3.60, 4.70, 5.60, 6.30.

Round wire: 2.50 - 5.0mm.

Slot opening: 0.05mm, 0.08mm, 0.10mm, 0.15mm, 0.2mm, 0.3mm, 0.6mm, etc.

Round wire diameter: 2.50 - 5.0mm.

Diameter: 20 - 1000mm.

Length: up to 6 meters.

Filter type: from outside to inside or inside to outside.

End Connection: welded rings ( plain beveled ends for butt welding) or threaded male and female coupling ( spiral) .

Packing: in wooden cases, boxes lined with waterproof material.

Feature:

Low- carbon, galvanized or stainless steel construction.

More open area and high precise openings.

Maximum design flexibility.

More stronger and durable.

High mechanical strength.

Resist pressure, high temperature, aging, corrosion.

Easier installation and long- term operating.

Low operation cost and maintenance cost.

Easy to clean for reuse.

Application:

Wedge wire filter element is widely used for deep well pump, dive water pump.

Also used for waste water treatment, water softening treatment, oil industry, food process, mineral process, and chemical and alkali filtration.

Wedge wire filter element drawing about support wire, wedge wire, slot opening

Wedge wire filter element drawing make it easy to understand wedge wire filter element structureA drawing about the normal external radial wire

Normal external radial wire

A drawing about the inverse external radial wire

Inverse external radial wireA drawing about the internal axial wire

Normal internal axial wire

A drawing about the normal internal radial wire

Normal internal radial wireA drawing about the normal internal axial wire

A drawing about the normal external axial wire

Normal external axial wireA drawing about the inverse external axial wire

Inverse external axial wire

Many bulked stainless steel wedge wire filter elements in stock

Stainless steel wedge wire filter element in stock to meet customers requirementsMany bulked and plastic cloth packing galvanized wedge wire filter elements in stock

Galvanized wedge wire filter element in stock

Many stainless steel wedge wire filter elements packed with plastic cloth in wooden carton

Wedge wire filter element plastic cloth packing in wooden cartonMany cartons wedge wire filter elements are fastened with metal belt in final

Wedge wire filter element wooden packing fastened with metal belt

Many wedge wire filter elements bulks in wooden cartons

Wedge wire filter elements bulks in wooden cartonMany wedge wire filter elements packed in wooden cartons

Wedge wire filter elements wooden packing makes good use of the space

Many wedge wire filter elements bulks in container

Wedge wire filter elements bulks in containerA forklift load wedge wire filter elements with plastic cloth to the container

Wedge wire filter elements with plastic cloth packing loaded with forklift
