Color Steel Standing Seam Roll Forming Machine Exported To Ghana Tw 33 300 - China

price: 33000.00 Dollar US$

Color Steel Standing Seam Roll Forming Machine Exported To Ghana TW-33-300

Working Flow
Decoiler ---> Fedding Guide ---> Roll Forming ---> Cut-to-length ---> Run out table

Coil Material
1)Thickness:0.3mm-0.8mm G250pa-350pa
2)Coil feeding width: Depend on custom-made
3)Material of roller:PPGI, Color steel, GI. Aluminium

Decoiler
Coil feeding width:Max.1250mm, Depend on custom-made

Standing Seam Forming Machine
1)Roll forming stations:11 stations (Depend on Profiles )
2)Roller material:45# steel, surface coated with 0.05mm hard chrome
3)Diameter of shaft: ∅76mm
4)Shaft material: High grade 45#steel
5)Drive type: Chain transmission
6)Forming speed:0-15m/min
Main Power:5.5KW

Hydraulic cutting
1)Cutting system: Hydraulic cutting
2)Cutting power:4KW
3)Length tolerance:10m+/-1.5mm

Electrical control System
1)PLC:PANASONIC Brand or Custom-made
2)Touch screen:PANASONICE or Custom-made

Output table
1)Table type: Simple nonpower type
2)Function:To support the finished panels

Machine Weight: about 5 Ton

Advantages:
High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience


Company Contact:


  • Phone: 86-15861597732

  • Address: Jingshi Road, Xibei Town, Xishan District, Wuxi, Jiangsu, China

  • Email: Email


Published date: July 29, 2016 -

  • Business Description: Wuxi Techwell Machinery Manufacturing Co.,Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panels machines and slitting cutting machines.

    Roll Forming Machines: Metal roof wall roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, floor deck roll forming machine, guardrail roll forming machine, downspout roll forming machine, gutter roll forming machine, portable downpipe machine, portable gutter machine, roller shutter door roll formng machine, k-span arch roof roll forming machine, Slitting cutting machine line, roof curving machine, stacker machine and so on.

    Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rock wool sandwich panel machine, mineral wool sandwich panel machine and so on.

    Our machines are very popular in Middel East, South East Asia, Africa, South America and East Europe, such as India, Iran, Australia, Canada, Bangladesh, Indonesia, Myanmar, Chile, Saudi Arabia, Brazil, Romania, Dominica, Panama, Turkey, Russia, Uraguay, Souch Africa, U.A.E, Ghana, Malawi, Nigeria, Zambia...

    Our Goal is to supply best quality machine and best service with reasonable price for our customers. We sincerely hope to cooperate with worldwide customers for our mutual success, and we warmly welcome to visit our factory.
