Eps Sandwich Panel Production Machine - China

ESP sandwich panel production machine could make the polystyrene core sandwich panel.

This sandwich panel product line adopts PLC and touch screen controlling system.

It could make both roof and wall sandwich panel with core of polystyrene foam material.

EPS Sandwich Panel Production Machine Suppliers, hot sale

Technical Data of EPS Sandwich Panel Production Machine

EPS Sandwich Panel Spec

Panel thickness Mini thickness 50mm (wall panel) Max.

thickness 200mm(exclude corrugated sandwich panel)

Steel Sheet Spec Thickness 0.4-0.7mm color steel sheet

Width 1250mm (we can design according to buyer’s requirement)

Max.

coil weight 5 tons

Inner Dia.

of coil 508mm

Whole Line Spec

Whole line dimension about 35000mm × 2500mm × 3000mm

Total weight About 18t

Working speed About 5-7m/min (adjustable)

The output 1500m2-2000m2/8hour

Control mode PLC and converter

Total power About 28Kw (as per final designing)

Power required 380V/3phase/50Hz or as per customer's requirement.

Air pressure 0.7Mpa (for buyer to prepare)

Suitable working temperature About 25 degree

Consecutive laminating body makes EPS blocks stick to up and down sheets

Product Application of EPS Sandwich Panel Production Machine

Due to its simple operation, this forming machine is widely used in the construction of steel structure enclosures, warehouse, workshop, cold storages, and mobile buildings.

Sandwich Panel Production Line, PU Sandwich Panel Production Machine, EPS Sandwich Panel Production Machine FactoryIn order to satisfy various customer requirements, we design and manufacture PU sandwich panel lines in different specs, models and configurations.
