Forming Speed 0 -15m Minstone Coated Roof Tile Macine For Making Sheet Wall - China

price: 35000.00 Dollar US$

0-15m/min Forming Speed Stone Coated Roof Tile Macine For Making Sheet Wall

Product Details:
1)Brand Name: TECHWELL
2)Certification: CE, BV
3)Model No.:TW-CSCTM

Product Specification:
1)Material thickness:0.3mm-0.7mm
2) Material width: depend on customer’s requirement
3)Decoiler Type: manual or automatical type ( depend on customer’s requirement )
4)Weight Capacity Of Decoiler: 5 Ton
5)Main Motor Power: 5.5 Kw
6)Hydraulic Motor Power: 11 Kw
7)Forming Station: 13-22 ( depend on profile drawing )
8)Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
9)Main Axis Material: High grade 45#, quenched and heat treatment.
10)Axis Diameter: ¢ 75mm
11)Working Speed: 0-15 m/min
12)Transporting Type: Chain Transmission
13)Heat Treatment of Cutting Blade: HRC 50-60
14)Type of Cutting: Hydraulic cutting
15)Material Of Cutting Blade: C r 12

Product Description
Color Stone coated steel roof tile sheet is formed by 0.4mm Al-Zn plating panel and color stones. It is modern, environmental and nice appearance. colorful coated metal roof tile is a new advanced roof material which adopt the high and new technology, use the non-corrosibility al-zin steel as the basic plate, use the acrylic resin which has the good weather resistance as the adhesives, use the colorful natural sandy gravel as the surface.Because of its nice appearance, lightweight, durable and environmental, it is becoming the major product in the international roof materials in recent years, and it is also used in the high-grade building in domestic, it is enjoying a great popularity all over the world.


Company Contact:


  • Phone: 86-15861597732

  • Address: Jingshi Road, Xibei Town, Xishan District, Wuxi, Jiangsu, China

  • Email: Email


Published date: July 29, 2016 - Modified date: July 29, 2016

  • Business Description: Wuxi Techwell Machinery Manufacturing Co.,Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panels machines and slitting cutting machines.

    Roll Forming Machines: Metal roof wall roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, floor deck roll forming machine, guardrail roll forming machine, downspout roll forming machine, gutter roll forming machine, portable downpipe machine, portable gutter machine, roller shutter door roll formng machine, k-span arch roof roll forming machine, Slitting cutting machine line, roof curving machine, stacker machine and so on.

    Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rock wool sandwich panel machine, mineral wool sandwich panel machine and so on.

    Our machines are very popular in Middel East, South East Asia, Africa, South America and East Europe, such as India, Iran, Australia, Canada, Bangladesh, Indonesia, Myanmar, Chile, Saudi Arabia, Brazil, Romania, Dominica, Panama, Turkey, Russia, Uraguay, Souch Africa, U.A.E, Ghana, Malawi, Nigeria, Zambia...

    Our Goal is to supply best quality machine and best service with reasonable price for our customers. We sincerely hope to cooperate with worldwide customers for our mutual success, and we warmly welcome to visit our factory.
