Galvanized Steel Silo Corrugation Machine With 18 Forming Stations - China

price: 33000.00 Dollar US$

Galvanized Steel Silo Corrugation Machine With 18 Forming Stations

Product Details
1)Place of origin: China
2)Brand name: TECHWELL
3)Certification: CE
4)Model No.:TW-SILO

Working Flow
Loading coil car -> Un-coiler -> guiding device -> feeder -> leveller -> shear roll former -> hydraulic press -> curving -> hydraulic cutting -> stacker -> PLC control

Main Specifications
1)Suitable material: Galvanized sheet, Zinc Alumina sheet
2) Material yield strength: 310Mpa
3) Material thickness: 2.5-4.0mm
4)Max. Feeding coil width: 1250mm
5)Machine working speed: 4-8mmin
6) Forming station: approx 18 stations
7) Size of roll shaft: Ф120mm
8) Roller material: GCr15, quenching HRC 58-62 °
9) Total power: approx 180KW
10) Power supply: AC440V+/-10%, 50Hz, 3 Phase
11) Whole line dimention: about 35M X 4.5M ( L X W )
12) Installation height: 4.5m
13) Total weith of machine: approx 70 tons

Advantages
High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience


Company Contact:


  • Phone: 86-15861597732

  • Address: Jingshi Road, Xibei Town, Xishan District, Wuxi, Jiangsu, China

  • Email: Email


Published date: July 29, 2016 -

  • Business Description: Wuxi Techwell Machinery Manufacturing Co.,Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panels machines and slitting cutting machines.

    Roll Forming Machines: Metal roof wall roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, floor deck roll forming machine, guardrail roll forming machine, downspout roll forming machine, gutter roll forming machine, portable downpipe machine, portable gutter machine, roller shutter door roll formng machine, k-span arch roof roll forming machine, Slitting cutting machine line, roof curving machine, stacker machine and so on.

    Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rock wool sandwich panel machine, mineral wool sandwich panel machine and so on.

    Our machines are very popular in Middel East, South East Asia, Africa, South America and East Europe, such as India, Iran, Australia, Canada, Bangladesh, Indonesia, Myanmar, Chile, Saudi Arabia, Brazil, Romania, Dominica, Panama, Turkey, Russia, Uraguay, Souch Africa, U.A.E, Ghana, Malawi, Nigeria, Zambia...

    Our Goal is to supply best quality machine and best service with reasonable price for our customers. We sincerely hope to cooperate with worldwide customers for our mutual success, and we warmly welcome to visit our factory.
