Steel Silo Corrugated Roll Forming Machine For Mental Sheets Galvanized Sheet - China

price: 33000.00 Dollar US$

Steel Silo Corrugated Roll Forming Machine For Steel Corrugated Sheets, Galvanized Sheet

Product Details:
Place of Origin:China
Model Number:TW-SILO
Payment Terms:40% T/T in advance, 60% T/T before shipment
Supply Ability:20 sets/month

Specification:
Suitable material: Galvanized sheet, Zinc Alumina sheet
• Material yield strength: 310Mpa
• Material thickness: 2.5-4.0mm
• Max. Feeding coil width: 1250mm
• Machine working speed: 4-8mmin
• Forming station: approx 18 stations
• Size of roll shaft: Ф120mm
• Roller material: GCr15, quenching HRC 58-62 °
• Total power: approx 180KW
• Power supply: AC440V+/-10%, 50Hz, 3 Phase
• Whole line dimention: about 35M X 4.5M ( L X W )
• Installation height: 4.5m
• Total weith of machine: approx 70 tons

Working Flow
Loading coil car -> Un-coiler -> guiding device -> feeder -> leveller -> shear roll former -> hydraulic press -> curving -> hydraulic cutting -> stacker -> PLC control
