introduction of duct rodder: Duct rodder are composed of fiber glass rod

which is extruded by fiber glass and high strength resin at high

temperature.

This type of rod has high tensile strength and flexibility.

It was covered by a high density polyethylene engineering plastic as its

protect layer, which make duct rodder cover sliding on surface,

durable, corrosion resistant and has good insulation performance, which

make them safe for using in cable occupied duct.

High Density

polyethylene(grade: for insulating and jacketing of Telecommunication

cables) is used in the outer diameter coating.

Duct rodder will be

equipped with different size reel according to the length of rod.

There

are wheels on the reel, which make it convenient for moving.

Features

and Benefits: Light weight, durable, resistance to acid and alkali,

aging resistant, corrosion resistant.

High tensile strength and bending

properties, which make it go through narrow pipes easily.

Perfect

temperature adaptability, the product will not soften in hot weather or

become brittle in the cold weather.

Cover was coated with long-term UV-

resistant polyethylene.

There are meter marks on the surface of duct

rodder, which can be used for measuring distance.

There are several

colors for your choice.

Technical Data of Duct rodders : Property value

Model specification 4.5mm, 6mm, 8mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mmfor

your choice, and we can also accept OEM order Length

30, 50, 60, 80, 100, 120, 150, 180, 200, 250, 300, 350, 400, 450, 500 meters for

choice.

Material Fiberglass (inner) and high density polytgtkebe(outer)

Density >1.9gr/cm3 Working temperature - 40 to + 80 Minimum pulling

strength 4000 N±5% Tensile Modulus >46.500Mpa Consistency of rod 137gr/m

Flexural Modulus >46.500Mpa Elongation at Break 2.5-3% Min.

Bending

Radius 388m Tensile Strength >15N/mm2 Environmental Stress & Crack

Resistance >1000hr

Continuous Rods On Mobile Reels

Please inquiry for your need now
