  • Bogie Hearth Furnace With Full Fiber Lining - China

    price: contact company for price

    It's energy-efficient semi-continuous operation of electric furnace,

    insulation effect significantly. mainly used for high-chromium, high

    manganese steel castings, ductile iron, Roller, Ball, Crusher

    hammerhead, wear-resistant liner quenching, annealing, timeliness and

    various mechanical parts used heat treatment.

    More detailed technical___directly sale Tel:027-83372766 83372755 13807177084

    Technical parameters:

    Parameters Name Unit Model

    RT3-30-9 RT3-65-9 RT3-75-9 RT3-90-9 RT3-105-9 RT3-150-9

    Rating Power KW 30 65 75 90 105 150

    Rating Voltage V

    Highest Temperature ℃

    Working Temperature ℃

    Phase Number 3 3 3 3 3 3

    Hearth

    size Length mm 950 1200 1500 1800 1800 2000

    Width mm 500 600 750 900 900 1000

    Height mm 450 450 600 600 650 700

    heating element Y Y Y Y Y Y

    heating-up time h

    lose power KW ≤18 ≤19 ≤17 ≤32

    control accuracy ℃ ±1 ±1 ±1 ±1 ±1 ±1

    niformity ℃ ±8 ±8 ±8 ±8 ±8 ±8

    Maximum Loading Kg 500 1000 1500 2500 3000 4500

    Weight Kg 2800 4000 4500 4800 5200 8000

    RT3-180-9 RT3-220-9 RT3-250-9 RT3-270-9 RT3-280-9 RT3-300-9

    Rating Power KW 180 220 250 270 280 300

    size Length mm 2100 2500 2400 3000 2400 2400

    Width mm 1050 1300 1500 1500 2000 2000

    Height mm 750 900 800 1000 1500 1700

    heating-up time h ≤2.5 ≤3

    ≤3.5

    lose power KW ≤39 ≤55 ≤67 ≤70

    Maximum Loading Kg 5000 7000 8300 9000 10000 11000

    Weight Kg 9000 12500 13000 14500 18400 19200


    Company Contact:


    • Phone: +862783372568

    • Address: No.18,Industrial Park,Wuhan Yinhu Technology Dongx, wuhan hubei China , China

    • Email: Email


    Published date: April 17, 2013 -

    • Business Description: Wuhan City Hankou Electric Furnace Limited Liability Company is a

      famous large industrial electric furance plant in china.And it has

      invested built up a 50000 square meters large industrial plants in

      Wuhan Dongxihu District, with powerful manufacturing ability it has an

      annual output of nearly 1,000 large heat treatment furnace.Now as a

      leader of China furance and heat treatment equipment industry it has

      been a important furnace production supply base in china.

      The company has 40 years' manufacturing experience,its patent product, that is Bogie hearth Resistance Furnace and Pre Pumped Vacuum and Protective Atmosphere Furnace are exported to Japan、Amereica、Indonesia、Singapore、Thailand etc many countries. Variety complete product specifications. Type of production: Furnace, Electric Furnace, Bogie hearth Electric Furnace, Pit Electric Furnace, Box Electric Furnace, Crucible Melting Electric Furnace, Carburizing Electric Furnace, Nitriding Electric Furnace, Drying Oven, Salt bath Furnace, Oil tank, Rotary Furnace, Vacuum Tube Furnace, Cylinder Furnace......

      Our plant develops usualness inter access technology communication with more than ten international famous electric furnace manufacturing companys, innovate furnace manufacturing technology and production processes, special components of electric furnace improving technology, product upgrading technology, it makes our plant keep synchronization with the international advanced industrial furnace manufacturing technology no whether in the type, the updating of furnace, fundation material progress, components manufacturing technology progess, manufacturing automation, and the way the loading of the loading basket manufacturing technology, WDS lining energy saving techniques, ceramic fiber wave of high pressure tied ceiling stack technology, oxidation free protection atmosphere, carburizing, nitriding, molten, salt bath, nitrate Austempered, precision heat treatment process, equational flow and temperature heat transfer asymmetric quenching tank manufacturing technology, microcomputer program heat treatment technology curve temperature control process, and so on can keep pace with internationa advanced industrial electric furance manfacturing technology.Some industrial furnace have been exported to Europe, the United States, Japan and other developed industrial countries as well as the Asian region, in this case it enjoys a higher international popularity.
