Keylocking Threaded Inserts - Chinaprice: contact company for price
are sure of them with high quality. And we also could do them by the
customers special request.
Keensert threaded insert are high strength threaded inserts made from the stainless steel and the carbon steel. They are passivated according to EN2516. Our standard inserts range contains Metric thread dimensiioins. Imperial dimensions and specials are available upon request.
Keensert threaded insert may be used in alloys, light materials, steel and cast iron to increase the strength of the thread in these materials. They can also be used for thread repair, whereas the defect thread can be replaced with the same nominal diameter.
Keensert threaded insert have less attrition. A multiple tightenting and lossening of the bolt is possible. Locking inserts include a dry film lubrication on the surface to protect the screw from galling.
Keensert threaded insert have a positive lock against rotation and vibration.
Keensert threadeed insert have 2 and 4 pre- assembled kees depending on the diameter. After installation of the kees into the parent material the assembly is form- closed. No check with a thread gauge according to the DIN standard possible in the area of the kees.
Pull- out- strength for Keensert calculation as follows:
Pull- out- strength( N) =shear engagement ( mm2) X ultimate shear strength of parent material ( N/ mm2)
type size inner( 6H) outer( 6g) length drill
min M2 M2* 0.4 M4* 0.7 3 3.4
M2.5 M2.5* 0.45 M4.5* 0.75 3.8 3.9
M3 M3* 0.5 M5* 0.8 4.2 4.4
M4 M4* 0.7 M6* 0.75 5.2 5.5
thinwall M5 M5* 0.8 M8* 1.25 8 6.9
M6 M6* 1 M10* 1.25 10 8.8
M8 M8* 1.25 M12* 1.25 12 10.8
M10 M10* 1.5 M14* 1.5 14 12.8
M12 M12* 1.75 M16* 1.5 16 14.8
heavy duty M4 M4* 0.7 M8* 1.25 8 6.9
M5 M5* 0.8 M10* 1.25 10 8.8
M6 M6* 1 M12* 1.25 12 10.8
M8 M8* 1.25 M14* 1.5 14 12.8
M10 M10* 1.5 M16* 1.5 16 14.8
M12 M12* 1.75 M18* 1.5 18 16.8
- Posted By: Xinxiang Aode Brother Insert Co., Ltd
- Phone: 863735858852
- Address: No. 173 Hongli R. D, Xinxiang, Henan, China, xinxiang , China
- Website: http://www.xxinsert.com
Published date: December 18, 2015 -
- Business Description: We are Xinxiang Aode Brother Insert Co., Ltd from China. We Professionally offer all kinds of threaded insert. Including the keylocking threaded insert. The selftapping threaded insert. The wire threaded insert, the tangless threaded insert. The threaded insert with a slot. The installation tool for them and so on.
We are sure of them with high quality and competitive price. If you are interested in us. Welcome contact us.
