Manual Rotary Pipe Swaging Machine - China

Manual Rotary Pipe Swaging Machine

Rotary Pipe Swaging Machine Model: TF-38F

Max.

Tapering Capacity: ￠38.1 (1.5”)×2mm

Max.

Tapering Length: 300mm

Length Accuracy: +/-0.5mm

Swaging Motor Power: 4 Kw

SLS Manual Rotary Pipe Swaging Machine also know as pipe tapering machine or pipe cone machine is a special kind of pipe cold forming machine.

In other words, rotary swaging is designed as a cost-efficient alternative to traditional metal forging and machining operations.

The function by using four die rotary hammering mechanisms to taper a tube to its final form.

As the tube is fed into the machine, it will be swaged by the dies to taper it into the desired form, which will be set according to the specifications on the control mechanism.

By applying German advanced technology and good mechanism&electrical quality controlling, machine with extremely advantage of low noise.

It is the practical manual rotary swaging solution for small to medium productions

STANDARD

Operation panel offers easy operation of machine.

All the parts are made under very strict quality control, so the quality of machine is in high level and the specification is standardized.

Machine featured as manual pipe loading, manual pipe feeding into machine, automatic rotary swaging.

A high quality tapering machine will use tools that move the dies in and out, offering as many as 3000 blows per minute to hammer the tube into the desired shape.

The thickness of the pipe and the strength of the material to be tapered will also impact how the materials should be prepared to create a clean tapered edge.

Available pipe material: steel, stainless, aluminum, titanium and brass.

The design of the tooling help customer easy to change.

Very Low noise during working: 75-85db.

CE&ISO 9001: 2000.
