Pneumatic V Port Titanium Ball Valve - China

Pneumatic V Port Titanium ball valve

Titanium ball valve

Ball valve

Manual Valve

titanium valve, Industrial valve

Technical Specification

Design Standard: API, ASME, EN, ISO, JIS, DIN, BS, GB

Connection type: Flange, Wafer, SW, NPT, BW

Pressure range: 150LB~1500LB, 1.0MPa~25.0MPa, JIS10K~100K

Size range: NPS3/8”-32”, DN10~DN800

Drive: Lever, Gear, Electric, Pneumatic actuator Design Feature:

Resilient seal or Metal to metal seal

Full bore or Reduce bore

Fire safe design, Anti-static device, Blow-out proof stem, Double block and bleed function

Grease injection for seat & stem

Cavity pressure self-relief

Optional lockable device

Anti-leakage design packing & packing box

ISO 5211 mounting pad

The surface form a protective film after Hard face treatment for trim.

It not only improves anti-corrosion performance, but also can open and close easily because of improved surface hardness.

Main Part Material :

Titanium Gr2, Gr3, Gr5, Gr6, Gr7, Gr12

Titanium GrC2, GrC3, GrC5, GrC6, Ti-Pd7B, GrC12

Titanium GrF2, GrF3, GrF5, GrF6, GrF7, GrF12

Company Contact:

• Posted By: Weidouli Valves Co.,Ltd

• Phone: 86-577-86921659

• Address: No.20,Xingyu Road,Airport Industiral Zone,Wenzhou City,Zhejiang Province,P.R.China, Wenzhou , Zhejiang , China

• Email:

• Website: https://www.wsv-valve.com

• Business Description: Weidouli Special Valves(WSV), Chinas leading valve manufacturer, specialize in industrial valves production, research & development, sales and service.

  History

  Founded in 1989

  Factory

  1st Factory: 9500m2

  2nd Factory: 33600m2

  People

  160 staffs

  Quality

  (DNV) ISO9001, ISO 14001, OSHAS 18001, API 6D, API 607/6FA, CE , TS etc.

  approvals.

  Equipment

  Over 100 sets including CNC and multi-station, Vacuum welding equipment, Vacuum heat treatment furnace, Vacuum surface modification.

  Test equipments

  such as NITON XRF Alloy analyzer, Direct reading spectrometer, Metallurgical microscope, Ultrasonic thickness measurement, Burawoy hardness test, Nondestructive test etc.

  Specialty

  Entirely focused on industrial valves for severe services

  Product line

  WSV Valves are built in high corrosion resistant performance materials: duplex and super duplex, titanium alloy, nickel alloys (Hastelloy?, Incoloy?, Inconel?, Monel?, Alloy 20, etc.

  ), zirconium and corrosion resistant alloys across all major industrial applications.

  Our products includes ball, gate, check, globe, butterfly, plug, control etc.

  valves

  Application

  Valves are delivered worldwide to the chemical engineering, mining project, metallurgy,

  pulp and paper making, power generation, natural gas and offshore and onshore other specific demand applications.
