Round Flange Rotary Airlock Valve - China

price: contact company for price

Rotary valve

Introduction

The TGFY- B rotary valve is suitable for viscous material discharging. Rotary valve rotor are easy to be filled by sticky material and lead to reduce capacity and even congestion. The TGFY- B rotary valve use intermittent high pressure air to clean adhesion material on the blades. Guarantee work efficiency and save energy .

Specification

Type TGFZ

Product material Powder / granule / other

Capacity 1T- 25T/ h

Flange Square

Out- bearing Yes

Body Material SS 304/ Cast iron/ Carbon steel

Rotor speed 20- 45 rpm

Rotor vane 4- 10 vanes

Drive arrangement Direct connection

Motor Variable frequency motor

Power and voltage 1.5Kw 380V ( variable)

Color Buhler blue ( variable)

Certification ISO9001: 2008

Patent ZL200720079396.9

Options & Accessories

Motor : SEW / Hard tooth helical gear reducer/ GUOMAO/ TONGLI/ Variable frequency motor

Closed end / Open end rotors

Adjustable Bladed Rotors / Elastic Poliurethane Bladed Rotors
