Model Application Advantages

BAg-1 Ordinary solder, applicable in all the parent metals except the light alloy the solder with low melting point

BAg-1A ” Good fluidity, applicable in the small weld

Bag-2 ” Big melting range, fit for the weld with big clearance

Bag-3 The stainless steel, the tungsten, the molybdenum, the carbide, the cast iron fit for the corner welding

Bag-4 The melting point is higher than BAg-3, the tool steel, the stainless steel, the cast iron, common lathe tool, plane knives and so on Fit for the high temperature welding, especially for the materials with high carbon amount, strong thermos table in the weld

Bag-5 Stainless steel, electric appliance, piping used in vessels, medical appliance, chemical instrument Fit for the high temperature welding, , used in the connection of big clearance

Bag-6 Food appliance, brass, nickel, electric appliance, galvanized iron sheet, tinned iron sheet Used in the high temperature welding, the electric conductivity is 24% of that of CU

Bag-7 Uses the monochrome with the stainless steel, fit for the low temperature welding of the non-CD food class appliance Can reduce the breakage caused by the stress corrosion

Bag-8 Used in the vacuum welding The electric conductivity is 77.1% of that of CU, cannot be spread in iron metal

JISSpec chemical ingredient（%ᦀ 9; Temperature（℃ ;) Stretch% Longitudinal strengthkg/m2 Proportion

Ag Cu Zn Cd Others Coagulation Liquefaction Welding temperature

BAg-1 44-46 14-16 14-18 23-25 - 605 620 620-760 20-25 40-50 9.4

BAg-1A 49-51 14.5-16.5 14.5-18.5 17-19 - 625 635 635-760 25-30 40-50 9.4

Bag-2 34-36 25-27 19-23 17-19 - 605 700 700-845 20-25 38-45 9.1

Bag-3 49-51 14.5-16.5 13.5-17.5 15-17 Ni

2.5-3.5 630 690 690-815 25-30 35-70 9.5

Bag-4 39-41 29-31 26-30 - Ni

1.5-2.5 670 780 780-900 25-30 50-60 9.0

Bag-5 44-46 29-31 23-27 - - 675 745 745-845 20-25 32-40 9.1

Bag-6 49-51 33-35 14-18 - - 690 775 775-870 21-26 32-40 9.3

Bag-7 55-57 21-23 15-19 - Sn

4.5-5.5 620 650 650-760 23-28 32-40 9.3

Bag-8 71-73 27-29 - - - 780 780 780-900 20-25 32-40 10.1
