Extruder Screws And Barrels For Blow Molding Machine - China

price: contact company for price

Screw barrel for blow molding machine

Specification

Screw diameter: Ø12-300MM L/D:10-55

Barrel diameter: Ø25-500MM Length:300-1000MM

Material

38CrMoAlA(JIS SACM645)

42CrMo(AISI 4140)

Cr12MOV(JIS SKD-11)

4Cr5MoSiV1(JIS SKD-61)

9Cr18MoV, etc

Parameter

Depth of Nitrated Layer: 0.5-0.8mm

Heat treatment: Nitriding 96 hours

Hardness of nitration: 900-1020Hv

Fragility of nitration: Less than grade 1

Surface roughness: Ra 0.4um

Feature

Screw is processed by special arts to be durable, resistant

tear and wear for long life

Different L/D is according to different requirement


Company Contact:


  • Phone: 8615957480610

  • Address: Room 901.Building No.2, Lane 165, Yunxia Road, Nin, Ningbo, China

  • Email: Email


Published date: March 5, 2014 -

  • Business Description: Ningbo Xuhao Industry is a work team of design, manufacture, and sales

    screw barrel for injection moulding machine, blow moulding machine,

    extruder machine, rubber machine, and other plastic machine. We own the

    advanced analysis equipment to ensure the quality of the material, heat

    treatment, alloy coating spraying, etc. All our screw barrel are

    customed made as drawing or machinery brand Number (Arburg, Autojector,

    Bettenfeld, Bipel, Boy, Bucher, Chen Hsong, Chaun LihFa, Cincinnati,

    Demag, desma, Dima, Dong Shin, Egan, Engel, Husky, JSW, Nissei, Toyo,

    Toshiba, Vistar, etc.)
