Screws And Barrels For Engel Injection Molding Machine - China

price: contact company for price

Specification

Screw diameter: Ø12-300MM L/D:15-55

Barrel diameter: Ø25-500MM Length:300-1000MM

Material

38CrMoAlA(JIS SACM645)

Cr12MOV(JIS SKD-11)

4Cr5MoSiV1(JIS SKD-61)

42CrMo(AISI 4140)

9Cr18MoV

Stainless steel, etc.

Parameter

Nitrided layer depth:0.50-0.80mm

Nitrided hardness: 900-1100HV

Nitrided brittleness: Less than 2 level

Surface roughness: Ra 0.4

Linearity of screw: 0.015mm

Feature

PMMA has no special requirements of design for screw barrel.

Because the melt viscosity is big, need deep screw slots and

large diameter shoot nozzle holes to plasticizing in low

temperature.


Company Contact:


  • Phone: 8615957480610

  • Address: Room 901.Building No.2, Lane 165, Yunxia Road, Nin, Ningbo, China

  • Email: Email


Published date: March 5, 2014 -

  • Business Description: Ningbo Xuhao Industry is a work team of design, manufacture, and sales

    screw barrel for injection moulding machine, blow moulding machine,

    extruder machine, rubber machine, and other plastic machine. We own the

    advanced analysis equipment to ensure the quality of the material, heat

    treatment, alloy coating spraying, etc. All our screw barrel are

    customed made as drawing or machinery brand Number (Arburg, Autojector,

    Bettenfeld, Bipel, Boy, Bucher, Chen Hsong, Chaun LihFa, Cincinnati,

    Demag, desma, Dima, Dong Shin, Egan, Engel, Husky, JSW, Nissei, Toyo,

    Toshiba, Vistar, etc.)
