Power Cable For E Bike Motor - China

price: 1.00 Dollar US$

Power cable for E bike motor bafang BBS mid motor

Name power cable

Model WYT-P-*095AT

Inlet/Outlet 2cores /6 cores

Rated voltage 60V AC/DC

Rated current power 15A, signal 2A

Withstand voltage 500V

Insulation resistance ≥20MΩ

Contact resistance ≤10mΩ

Mechanical life 200 times

Insertion force ≤100N

Pull out force ≥50N

Working temperature -25℃~+85℃

Protection grade IP66

Dimensions Male 12.6mm, Female 10mm

Overalllength 75mm

Contact element material gold-plating Copper alloy

Wire specification 2.0mm²+0.20mm²

ATINGS/CHARACTERISTICS

UL Recognized

RoHS Compliant

48 V

1To 3

MATERIAL

FEATURES

Most common Y splitter connector cable for Electric bike.

Lenght: can be any length needed.

Current: 2A

Life: 200 times

1T3

Waterproof cable: IP65 Sealed waterproof connectors, sturdy and durable

ENVIRONMENTS

Ebike controller


Company Contact:


  • Phone: 18758486780

  • Address: https://www.szwyte.com/, Suzhou City, Jiangsu Sheng, China

  • Email: Email


Published date: September 5, 2021

  • Business Description: Suzhou Grand Electronic Technology Co., Ltd. is a high-tech enterprise that produces advanced waterproof cables.

    It is located in Dongshan Town, Wuzhong District, Suzhou City, China, in the Jiangsu-Zhejiang-Shanghai Economic Triangle.

    Grand specialized in integrates research and development, production and sales, and its products are used in professional fields such as new energy vehicles, solar energy, aviation, aerospace, medical care, nuclear technology, and military applications.

    Grand has passed the ISO 9001 quality system certification, and its products comply with Chinese and foreign national standards, and have various certificates such as CE, ROSH, etc.

    And it has independently developed a number of patented products and has strong independent development capabilities.
