Ge Vmivme 7452 Single Slot Vmebus Floppy Hard Disk Module - China

price: 17000.00 Dollar US$

Ge Vmivme 7452 Single Slot Vmebus Floppy Hard Disk Module

Products Photos Catalog Vmivme 7452 Slot Photos Catalog

INTRODUCTION The VMIVME-7452 is a passive board that holds one floppy and one hard drive with an optional Flash drive available.

The board is a 6U VMEbus form factor, deriving its power from the standard VMEbus P1 and P2 - The VMIVME-7452 has been designed to interface to VMIC’s line of VMEbus-compatible PC/AT SBC boards.

These SBC boards incorporate the floppy and IDE controllers on-board.

Refer to the compatible SBC list in this specification.

FEATURES • Optional Flash drive • 3.5-inch 1.44 Mbyte floppy drive • Standard VMEbus 6U single-slot form factor • Low power SPECIFICATIONS Physical Dimensions: Standard VME double height Eurocard (one slot)160 x 233.25 x 20.32 mm User Connectors: 34-pin floppy drive 40-pin IDE Ambient Temperature: All Disks: 5 to 50 ˚C, operating Storage: -25 to 60 ˚C Rate: 20 ˚C per hr maximum Humidity: 20 to 80 percent, noncondensing, maximum wet bulb 29 ˚C Flash Drive System Performance: Data Transfer Rate to Flash: 4.0 Mbyte/s burst Data Transfer Rate from Flash: 6.0 Mbyte/s burst Sleep to Write: 2.5 ms maximum Sleep to Read: 2.0 ms maximum Reset to Ready: 50 ms, typical, 400 ms, maximum Flash Drive System Performance: DC Input Voltage (Commercial): 5 V ±10%, 3.3 V ±5% Power Consumption: Sleep: 200 µA at 3.3 V, 500 µA at 5.0 V Read: 32 to 80 mA at 3.3 V, 46 to 120 mA at 5.0 V Write: 32 to 80 mA at 3.3 V, 46 to 120 mA at 5.0 V


Company Contact:


  • Phone: wang@kongjiangauto.com

  • Address: No1134Jimei North Road, Jimei District, China, XiaMen , China

  • Email: Email


Published date: July 15, 2024

  • Business Description: We are located in the beautiful Fujian Province of China, with professional products and services and adequate inventory.

    Specializing in shipbuilding, chemical, petroleum, storage, natural gas, steel, subway and a series of chemical core equipment products.
