Heavy Duty Multi Axles Self Propelled Modular Steel Steering Axle Transporter Trailer - China

price: 28000.00 Dollar US$

Heavy Duty Multi Axles Self Propelled Modular Steel Steering Axle Transporter Trailer

Products Photos Catalog Heavy Duty Multi Axles Photos Catalog

Scheuerle 2.43 SPMT Conventional modular trailer is specialized for heavy load transportation, featured with strong structure and high loading ability.

Manufacturer, ChinaTrailers, brings in core technologies from German Goldhofer and makes some improvements to meet various clients need.

ChinaTrailers model SY-V3 uses Italy Lombardini engine and imported spare parts.

It can be fully coupled with German Goldhofer THP/SL.

Main parts we use as below: Material Q690E high-strength steel

Hydraulic Sealing Parts PARKER (USA)

5 Joints Multi Way Valve BONDIOLO& PAVESI (ITALY)

Stop Valve STAUFF (GERMAN)

Tyre 215/75R17.5 DOUBLE COIN (CHINA)

Hydraulic Hose AEROQUIP (GERMAN)

Quick Coupling VOSWINKEL (GERMAN)

Cylinder HAITE (CHINA)

Slew Bearing ROTHE ERDE (GERMAN) Main technical features as below: Wheelbase 1500mm

Trend 1800/735mm

Minimum ground clearance 148mm

Height of platform 1175± 300mm

Suspension Hydraulic suspension

Support mode of platform 3 and 4 points suspension

Payload per axle line 22.5tons @ 18km/h

Max capacity per axle line 45tons


Company Contact:


  • Phone: +8613524300592

  • Address: 1st Floor, No.1990, Jinbi Road, Fengxian District, Shanghai, Shanghai , China (Mainland), China

  • Email: Email


Published date: May 8, 2020

  • Business Description: ChinaTrailers, a MANUFACTURER of special vehicle.

    Best Sellers

    -Hydraulic modular trailer (Goldhofer THP/SL; Nicolas MDED; Scheuerle model)

    -Self-Propelled Modular Transporter (SPMT)

    -Wind blade trailer (55 meters wind blade trailer)

    -Lowbed trailer (3 Axles 80 tons lowbed trailer etc.

    )

    Advantages

    -Reasonable price and convenient operation.

    -Professional technical solutions.

    -Free after sale service.
