Product Description

MT-A1230 series covers a wide range of powder coatings specifically designed to meet the extreme demands of automotive components.

Demanding environments require high performance protection.

MT-A1230 will enhance and protect automotive parts with excellent chemical, corrosion and chip resistance as well as the right aesthetic appearance exactly where it’s needed.

Powder properties

Chemical Type Epoxy-Polyester

Area of usage Automotive mechatronic components and systems

Related Specifications Brose 587000-110 / Group 2

Appearance Smooth

Gloss level (60°) 52 ± 4 GU

Colour Black

Recommended Film Thickness (µm) 80 ± 40 µm

Density (g/cm3) 1.46 ± 0.03

Gel time (at 200 °C) 36 – 54sec

Coverage at 60 µ

Coverage at 80 µ 93.0 g/m2 or 10.8 m2/kg

124.0 g/m2 or 8.1 m2/kg Application Corona Only – Electrostatic (30 – 100 kV)

Storage Under dry, cool (<25°C) conditions

Shelf life At least 12 months from production date

Curing schedule

(at object temperature) 10 minutes at 180°C

(please see curing window) Mechanical Tests

Adhesion DIN EN ISO 2409 Gt 0

Erichsen cupping DIN EN ISO 1520 ≥ 5 mm

Buchholz indentation DIN EN ISO 2815 > 80

Cylindrical mandrel DIN EN ISO 1519 ≤ 6 mm

Application

MT-A1230 powders can be applied by manual or automatic electrostatic spray equipment.

It is recommended that for consistent application and appearance product be fluidized during application.

Unused powder can be reclaimed using suitable equipment and recycled through the coating system.

Pre-treatment

Steel surfaces to be coated must be clean and free from grease.

For maximum protection it is essential to pre-treat components prior to the application of MT-A1230 - Iron Phosphate and Zinc Phosphate of ferrous metals improve corrosion resistance.
