Electrical Insulation Powder - China

Product description

This series of products is made of epoxy resin and curing agent as the main raw materials.

Features: —Good adhesion, good mechanical properties —Good electrical insulation —Excellent chemical resistance Use: Mainly used for metal materials with high insulation requirements such as motor housing, motor rotor, electric control cabinet, transformer equipment, etc.

Application parameters: Curing time: 120~200℃×10–30 minutes (adjusted according to customer coating conditions) Spraying method: high-voltage electrostatic spraying 60-80 KV Coating film thickness: 60-500 um Coating performance

Resistivity: Tested using a resistance meter, standard ≥10¹⁴ ohm·cm, test method GB/6554 - Impact resistance: Tested using an impact meter, standard ≥50 kg·cm, test method GB/T 1732 - Bending resistance: Tested using a bending tester, standard ≤2mm, test method GB/T 6742 - Adhesion: Tested using a cross-cut adhesion test, standard grade 0 - test method GB/T 9286 - Cupping test: Tested using a cupping apparatus, standard ≥6 mm, test method GB/T 9753 - Salt spray resistance: Standard ≥500 hours, ≥9 grade, test method GB/T 1771 - Moisture and heat resistance: Standard ≥1000 hours, slight loss of gloss, test method GB/T 1740 - If you're ready to take the next step or Request Free Samples, Leave your message below and we’ll reply soon.

20+ years of chemical manufacturing & export experience, a partner you can trust.
