Product Introduction:

This product is formulated using phenolic epoxy resin and incorporates modified conductive polymers and conductive materials, combining the advantages of intrinsic and doped conductivity.

It is specifically designed for conductive heavy-duty anti-corrosion powder coatings.

The surface resistivity of the coating can reach below 10⁵ Ω, effectively eliminating static electricity accumulation in gas drainage pipes and preventing static sparks, thereby enhancing safety.

The coating features high reactivity, strong adhesion, high cross-link density, and excellent resistance to chemicals, solvents, cathodic disbondment, as well as superior flexibility and impact resistance.

Product Usage:

Special anti-static and anti-corrosion coating for gas ventilation and drainage pipes in coal mines.

Product Features: Excellent adhesion to the substrate.

First application of a new material combining intrinsic and doped conductivity.

Good conductivity of the coating, with surface resistivity reaching 10⁵ Ω, effectively eliminating surface charge accumulation.

Superior high-temperature cathodic disbondment resistance.

Low melting temperature, high reactivity, high curing completion rate, and good mechanical properties.

Contains composite flame retardants, providing certain flame-retardant effects.

Powder Performance: Property Specification Notes

Adhesion Excellent Conductivity Surface resistivity below 10⁵ Ω Cathodic Disbondment Resistance Superior at high temperatures Flexibility Extremely strong, passes 4/5 flattening and post-grooving tests Temperature Resistance Good performance in high and low temperatures Flame Retardancy Contains composite flame retardants Curing Conditions: Property Specification Notes

Temperature Referenced to workpiece temperature Deviations may affect performance

Heating Method Medium-frequency heating or other heating methods Application Parameters: Parameter Specification Notes

Applicable Equipment Frictional charging spray, corona electrostatic spray, dip coating, roll coating Film Thickness 250-450um Adjustable according to workpiece requirements Health and Safety: Property Specification Notes

Toxicity Non-toxic Flammability Non-flammable Regulation GB15607-1995 Coating operation safety regulations Precautions: Item Specification Notes

Outdoor Use Not recommended May cause fading and chalking

Surface Preparation Oil-free, water-free, surface treatment to Sa21/2 level (GB/T8923), anchor pattern depth 40-100um, clean surface from dust and abrasives Preheating Temperature controlled between 180-250°C, not exceeding 250°C Storage Ventilated, dry, below 30°C, away from heat sources, corrosive chemicals, and solvents, avoid strong light, maximum stack height 5 layers, avoid long-term pressure, keep packaging sealed Curing Temperature Preheat steel pipe surface to above 200°C for better curing completion rate Compliance Standards:

MT 181-88 “Safety Performance Testing Specifications for Plastic Pipes Used in Coal Mines”
