Epoxy Anti Corrosion Powder Coating For Coal Mine Gas Drainage Pipes - China

Product Introduction:

This product is formulated using phenolic epoxy resin and incorporates self-developed conductive polymers and conductive materials, combining the advantages of intrinsic and doped conductivity.

It is specifically designed for conductive heavy-duty anti-corrosion powder coatings.

The surface resistivity of the coating can reach below 10⁵ Ω, effectively eliminating static electricity accumulation in gas drainage pipes and preventing static sparks, thereby enhancing safety.

The coating features high reactivity, strong adhesion, high cross-link density, and excellent resistance to chemicals, solvents, cathodic disbondment, as well as superior flexibility and impact resistance.

Product Features:

Excellent adhesion to the substrate.

Utilizes self-developed materials combining intrinsic and doped conductivity.

Good electrical conductivity of the coating, with surface resistivity reaching 10⁵ Ω, effectively eliminating surface charge accumulation.

Forms an anti-electric field at the coating-metal interface, shielding electron transfer and protecting the metal.

Superior high-temperature cathodic disbondment resistance.

Low melting temperature, high reactivity, high curing completion rate, and good mechanical properties.

Contains flame retardants, providing certain flame-retardant effects.

Powder Coating Performance Parameters：

Item Quality Indicator Test Method

Appearance Uniform color, no lumps Visual inspection

Density (g/cm³) 1.3-1.7 GB/T 4472

Non-Volatile Content (%) ≥ 99.4 GB/T 6554

Cured Powder Coating Performance Parameters：

Test Item Technical Indicator Test Method

Appearance Smooth surface, uniform color, no bubbles, cracks, or pinholes Visual inspection

Adhesion (Grade) 1-3 CJ/T 120-2008

Impact Resistance No peeling, no cracking CJ/T 120-2008

Surface Resistivity (Ω·m) ≤ 1×10⁶ (Ω·m) GB/T 16906-97

Abrasion Resistance (1000g, 1000 cycles) ≤ 20g GB/T 1768-1979

Alcohol Burner Flame Test Average flaming combustion time ≤ 3s MT 181-88 Maximum flaming combustion time ≤ 10s Average non-flaming combustion time ≤ 20s Maximum non-flaming combustion time ≤ 60s Bending Test No stripping or cracking of the inner coating CJ/T 120-2008

Flattening Test (Flattening ratio 4/5) No cracking, no stripping CJ/T 120-2008

Compliance Standard:

MT 181-88 Application Fields:

Special anti-static and anti-corrosion coating for gas ventilation and drainage pipes in coal mines.

Application Processes:

Electrostatic spraying, dip coating, roll coating, etc.

Precautions:

The steel pipe surface should be free of oil and moisture; the surface treatment quality should reach Sa2 1/2 level (GB/T 8923); the anchor pattern depth should be 40-90 mm; dust and abrasives on the steel pipe surface should be blown clean.

Preheating temperature should be controlled between 180-250°C and must not exceed 275°C.

The product should be stored in a well-ventilated, dry indoor environment with a temperature below 30°C, away from heat sources, corrosive chemicals, and chemical solvents, and protected from strong light exposure.

The stacking height should not exceed four layers.

Avoid long-term pressure and ensure the packaging box is sealed to prevent caking and moisture, which can affect fluidization performance.

To ensure thorough curing of the epoxy coating and better anti-corrosion performance, it is recommended to preheat the steel pipe surface to above 200°C to improve the curing completion rate.
