Powder Coating For Electrostatic Spray Application On Cold Surfaces - China

Product Description

MT R4-ES HJ601R is a high quality thermosetting epoxy powder coating for the corrosion protection of valves and fittings, manufactured from cast iron or steel.

The powder coating is applied in one layer on cold surfaces by electrostatic spray application.

The adhesion of MT R4-ES HJ601R to the metal substrate provides long term protection of the coated component.

It ensures a reliable conservation to the function and value of the parts for the common water and gas distribution network.

The applicator benefits from a modern and environmentally friendly process.

Drinking water approvals are available.

Powder Properties Typical value Method

Binder System Epoxy Density 1.30 – 1.40 g/cm³ ISO 8130-2

Gel time at 200° C 25 – 40 sec.

modified ISO 8130-6

Particle size distribution < 32 µm = 25 – 40 % < 125 µm > 98 % Malvern ISO 8130-1

Storage stability 6 months from date of manufacture at ≤ 23° C

Application

Data Curing conditions : 10 min., 190° C object temperature.

Material Properties

Color blue, ca.

RAL 5015 Recommended film thickness 120 – 220 µm Flow smooth Gloss at 60° angle 70 – 100 units ISO 2813

Cross cut Gt 0 DIN EN ISO 2409
