Transparent Powder Coating - China

Product Overview

This series of products is made of polyurethane or acrylic resin with curing agent, and is a transparent powder coating with high transparency and excellent flatness resistance.

Application areas

Main applications:

Automobile topcoat and exterior parts

Automobile wheel coating

Indoor and outdoor metal parts protection

High-performance finish layer for various metal appliances

Typical application scenarios:

High-end metal furniture

High-end hardware products

Bicycle parts

High-end door handles

High-end craft products

Gloss protection layer for metal powder coatings

Technical parameters

Basic properties of powder:

Specific gravity: 1.1~1.3g/cm³ Volatile matter: <0.5%~2% (depending on product type) Flow rate: >130 (with good fluidization and conveying performance) Features

Category Features Curing conditions

PE/TGIC Polyester/TGIC Good leveling, excellent weather resistance, good transparency 200℃/10min

Polyester/TGIC Good leveling, excellent weather resistance, good transparency 200℃/10min

PU polyurethane type Good leveling, excellent weather resistance, good transparency 200℃/15min

Acrylic/PU Mixed acrylic Good leveling, excellent weather resistance, excellent weather resistance, solvent resistance 200℃/10min

Acrylic Acrylic Excellent weather resistance and solvent resistance, Impact resistance can reach ±10kg.

com.

200℃/10min

170℃/20min 170℃/20min

Coating performance

Item Reference standard PE/TGIC PU type Acrylic/PU Acrylic

Appearance GB5237.4 Flat Flat Flat Flat

Leveling Q/TXSLD01-03 Grade C Grade B Grade B Grade A

Transparency Q/TXSLD01-03 Grade B Grade B Grade B Grade A

Impact GB/T1732-93 ±50kg.

cm ±50kg.

cm ±50kg.

cm ±50kg.

cm

Cupping GB/T9753-88 >6mm >6mm >6mm >6mm

Adhesion GB/T9286-98 Grade 0 Grade 0 Grade 0 Grade 0

Bending GB6742-86 Φ2mm Φ2mm Φ2mm Φ2mm

Indentation hardness GB9275 ≥80 ≥80 ≥80 ≥80

Salt spray test GB/T1771-91 No change after 1000 hours No change after 1000 hours No change after 1000 hours No change after 1000 hours

Wet heat test GB/T1740-79 1000 hours level 1 1000 hours level 1 1000 hours level 1 1000 hours level 1

Aging test Light aging Light aging: ASTMG154QUV0.78w/m2@340nm 500h Gloss retention rate ≥80% Gloss retention rate ≥80% Gloss retention rate ≥80% Gloss retention rate ≥80%

Note: The above tests all use 0.7mm thick degreased aluminum plates with a film thickness of 60-80μm; the above parameters are laboratory data and are for reference only.

The actual indicators are related to factors such as customer environment, equipment, substrate, pretreatment, and spraying process.

Packing specifications

Standard packaging: carton lined with plastic bag Net weight per box: 20kg Transportation classification: non-hazardous goods Safety instructions

Raw materials do not contain highly toxic substances Precautions for use: Avoid inhalation of dust (it is recommended to wear a dust mask)

Reduce direct skin contact

Skin contamination can be washed with soap

Avoid contact with chemicals during storage If you're ready to take the next step or Request Free Samples, Leave your message below and we’ll reply soon.
