Fabric Light Transmittance Testing Machine - China

Test standard :

JIS L1005-2009: Japanese standard for testing the dimensional stability of textiles to washing and drying.

FZ/T62011.1-201: Chinese textile industry standard specifying requirements and test methods for household textile products.

Test principle:

1 - A light source (light bulb) is illuminated, and the light is irradiated to the photodetector of the illuminance meter; 2 - Adjust the brightness of the light source to 10.000 (1X); 3 - Determine the illuminance of the sample; 1: illuminance (lx) after installation of the sample; I0: no illumination of the specimen (I1: I1 / I0) × 100%, I1: Lx).

Main feature:

1 - with the determination of spectral transmittance function.

2 - with the mouth and the photon detector integral ball.

3 - with an optical device capable of generating a double beam.

4 - two parallel beam of light and its beam axis of the incident angle of not more than 5 °.

5 has a function of scanning at a desired wavelength interval in the wavelength range of 380 nm to 780 nm.

6 - with the sample in the tension-free state to keep the sample folder.

Parameters:

Technical Parameters Specifications

Test Mode Automatic

Test Area 100 cm²

Sample Block Size 200mm × 200mm

Light Source 1000W Tungsten Lamp

Voltage Range 0-130V (for 110V input) / 0-230V (for 220V input)

Weight 50 kg

Power Supply 220V, 50Hz

Appearance Dimensions 650mm × 600mm × 1100mm

Illuminance Range 0-199.900 LUX (Adjustable)
