4ge Gpon Poe Ont - China

The GPON poe ONT is type POE (PSE) product, with 4 fixed 10/100/1000Mbps auto-adapted POE ports.

It supports IEEE802.3af 15.4W and IEEE802.3at 30W POE standards.

It can auto discovery the power receiving devices which support IEEE802.3af/at standard and supply power to it.

To the connected devices which not support PoE, it will auto stop supplying power.

The GPON POE ONU supports to work with IP camera, IP phone, wireless AP and other network devices, and supply power to these devices.

The POE ONT works with central device OLT to implement integrated management, long-distance fault location and decrease maintenance workload.

The GPON POE ONT is metal casing design and suitable for FTTB/FTTH.

It is mainly applied to security monitoring, smart city, tunnel monitoring, coal mine network etc.

The ONT can be installed on desk or wall.

Feature Apply to ITU-T G.

984/G.

988 Support auto discovery and auto register (real-time operation) Support DBA and multi types SLA Support IEEE802.1D RSTP Support IGMP Snooping V2 multi-broadcast function Support EMI and ESD identification Support VLAN Support user end auto time synchronization based at SNTP Support powerful OAM and remote management Support port speed limit, loop detection and port VLAN Support state detection and fault location Support power failure alarm Each PoE port supports to auto discovery the standard power receiving devices Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards

Parameter Specification Wavelength 1310(TX)/1490(RX) Optical power -1~+4dBm Receiving sensitivity -25dBm Max transmission distance 20 km

Space of buffer storage 1.25MB MTBF 100, 000 hours PON connector SC/PC EPON trait Support IEEE802.3ah Support Dynamic Bandwidth Allocation (DBA) Support ONU auto-searching and automatic registration (real-time operation) Standard and Protocol Support IEEE802.3, IEEE802.3u IGMP Snooping V2 Support IEEE802.1q WLAN Support IEEE802.1p QOS POE Supplying power port: 8 ports Standard: IEEE802.3af 15.4W, IEEE802.3at 30W Working mode: auto discover and power/dis-power receiving power device Network management Cooperating with center OLT, implement management configuration and software upgrade to ONU
